GV3000U-AC006-AA-DBT Image One
2 year warranty

GV3000U-AC006-AA-DBT Image 1
GV3000U-AC006-AA-DBT Image 2
GV3000U-AC006-AA-DBT Image 3
GV3000U-AC006-AA-DBT Image 4


    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
The AC power drive GV3000U-AC006-AA-DBT has a horsepower rating of 3 HP in both vector and Volts/Hertz regulator modes. The enclosure is NEMA 1. The power loss watts at full load is 140 A with an input amperage of 6.4 A.



Sell Surplus: Have a GV3000U-AC006-AA-DBT to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: GV3000U-AC006-AA-DBT
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

GV3000U-AC006-AA-DBT Technical Specifications

Catalog Number GV3000U-AC006-AA-DBT
US Model Number 3V4160
European Stock Number 896.03.80
Series GV3000
Manufacturer Reliance Electric
Instruction Manual D2-3360
Enclosure NEMA 1 or IP20
Keypad/Display Built-In Keypad
Phase 3 Phase
Input Voltage 380-460 VAC
Hz 50/60 Hz
kW 2.2 kW
Input Amps 6.4 A
Input KVA 5.1 KVA
Output Amps at 2, 4, and 8 kHz 5.3 A

Product Description

The GV3000U-AC006-AA-DBT drive is an AC power drive from Reliance Electric as part of their GV3000 series. The GV3000U-AC006-AA-DBT number is considered the catalog number. Two other part numbers are used to reference this drive, 896.03.80, the European stock number, and 3V4160, the US model number. The US model number is the part number most often when referencing this drive, as it is easiest to identify the different features and components. One example is the first character in the US model number, which identifies the horsepower rating. The horsepower rating of this model is 3 HP. Another feature of this drive, denoted by the US model number, is the input voltage which is 380 to 460 V, denoted by the third character in the US model number.

There are two sets of technical data when referring to the GV3000U-AC006-AA-DBT drive. One set is the inverter current, and the other is the motor power. The motor power has the same value when the module is in vector or V.hz mode. The value for the motor power is 2.2 kW. The inverter current values are different depending on the regulator mode. The current in vector mode is 5.3 A at 2 kHz, with the current in V/Hz mode at 5.8 A.

All of the above information about the GV3000U-AC006-AA-DBT drive comes from two specific manuals produced by Reliance Electric. One of the manuals is the D2-3360 GV3000/SE AC Drive Hardware Reference, Installation, and Troubleshooting Manual, which is specific to AC power drives. The other manual is the GV3000-UM060K-EN-P GV3000/SE AC General Purpose and Vector Drive Instruction Manual, which is used for identifying all of the GV3000 drives.

Frequently Asked Questions about GV3000U-AC006-AA-DBT

What are the fatal fault code errors on GV3000U-AC006-AA-DBT?
GV3000U-AC006-AA-DBT has some fatal fault codes, which are typically fault codes that indicate a malfunction of the GV3000U-AC006-AA-DBT microprocessor or GV3000U-AC006-AA-DBT's regulator board. The fatal fault codes that could appear on GV3000U-AC006-AA-DBT's keypad/display are fault codes: F3, F60, F61, and F62 or F26. F3 is the fatal fault code error on GV3000U-AC006-AA-DBT for encoder power-up diagnostic error. F60 is the fault code error for option port identification error on GV3000U-AC006-AA-DBT. F61 is the fatal fault for an option board power-up diagnostic failure. And fault codes F62 or F26 are the fault code errors for an option board runtime error on GV3000U-AC006-AA-DBT.
Which parameter selects the top speed of GV3000U-AC006-AA-DBT's motor?
The motor top speed parameter on GV3000U-AC006-AA-DBT is parameter U.017. This parameter selects the top speed that GV3000U-AC006-AA-DBT's motor can reach. The parameter has a range of U.005 to 7200 RPM and this parameter is a configurable parameter on GV3000U-AC006-AA-DBT. To determine the upper limit of parameter U.017, GV3000U-AC006-AA-DBT compares the results of two formulas and uses the lower value. To view the formulas to determine a parameter value on GV3000U-AC006-AA-DBT, view section 4-78 in the software manual for GV3000U-AC006-AA-DBT, Manual D2-3359.
What is GV3000U-AC006-AA-DBT's displacement power factor?
GV3000U-AC006-AA-DBT has a 0.96 displacement power factor.
Where can I find the manuals for GV3000U-AC006-AA-DBT?
We can provide you with both manuals for GV3000U-AC006-AA-DBT. The manuals to use with GV3000U-AC006-AA-DBT are Manuals D2-3359 and D2-3360, the software and hardware manuals for GV3000U-AC006-AA-DBT, respectively. We're happy to send you links to the manuals or you can find the manuals on our website.

Reviews For GV3000U-AC006-AA-DBT

Internal Review

One of the downsides of the GV3000U-AC006-AA-DBT drive is that there is no RFI filter or braking unit. Models that have an RFI filter and braking units are more advanced than drives without an RFI filter. Thus, if wishing to purchase a unit equipped with an RFI filter, look for part numbers that have RFI at the end of the part number. - AX Control Tech

Repair Services For GV3000U-AC006-AA-DBT

Type Lead Time Price Action
Repair Service 1-2 weeks $1225

Our highly skilled technicians can repair your GV3000U-AC006-AA-DBT. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
