The GV3000E-AC024-AA-DBU drive is one of the bookshelf drives made by Reliance Electric. This drive does not have a CE filter of any kind. The operating current is 24.0 A. The European stock number for this unit is 896.08.11.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a GV3000E-AC024-AA-DBU to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: GV3000E-AC024-AA-DBU
  • SKU: GV3000EAC024AADBURE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

GV3000E-AC024-AA-DBU Technical Specifications

Part Number GV3000E-AC024-AA-DBU
US Model Number 240ER4060
European Stock Number 896.08.11
Series GV3000
Manufacturer Reliance Electric
Instruction Manual D2-3426 & D2-3427
Enclosure IP20
Keypad/Display Built-In Keypad
Phase 3 Phase
Input Voltage 380-460 VAC
Hz 50/60Hz
Current Rating 24.0 Amps
Input Amps 31 A
Input KVA 24.7 KVA
Power Loss Watts (Full Load) 380

Product Description

Drive number GV3000E-AC024-AA-DBU is one of the bookshelf drives produced by Reliance Electric as part of their GV3000 drive series. This drive has two alternate parts: the European stock and US model numbers. The European stock number is 896.08.11, which will denote the power module's size and the components for the inverter, which are braking transistor circuits and DC-bus terminals for this model. The US model number is 240ER4060, which helps with the identification of potential filter types, the current rating, and regulator versions. The current rating for this drive is 24.0 A. According to the ER in the US model number, a CE filter is not available on this drive.

This drive has two sets of technical data for inverter current and motor power. The inverter current and motor power will differ between the regulator versions. When the model is in vector mode, the inverter current is 16.5 at 2 kHz, and the motor power is 7.5 A at 400 VAC. The inverter current in V/Hz mode is the same as the current rating, and the motor power is 11 A.

There are several power ratings associated with the GV3000E-AC024-AA-DBU drive; some examples of the power ratings are input KVA, input amps, and outputs amps in the regulator mode at the chosen carrier frequency. When the GV3000E-AC024-AA-DBU drive is in vector mode, the output amps are as follows, 24.0 A at 2 kHz, 16.5 A at 4 kHz, and 12.6 A at 8 kHz.

Frequently Asked Questions about GV3000E-AC024-AA-DBU

What are the manuals for GV3000E-AC024-AA-DBU?
There are two main manuals for GV3000E-AC024-AA-DBU. The manuals for GV3000E-AC024-AA-DBU are software and hardware manuals for GV3000E-AC024-AA-DBU. The manuals are D2-3426 and D2-3427, respectively. Both manuals are Reliance manuals and both manuals apply to bookshelf drives, which includes GV3000E-AC024-AA-DBU.
Which parameter is for terminal strip speed reference on GV3000E-AC024-AA-DBU?
Parameter P.008 is the parameter for terminal strip speed reference source on GV3000E-AC024-AA-DBU. This parameter on GV3000E-AC024-AA-DBU selects the source of the terminal strip speed reference on GV3000E-AC024-AA-DBU. The parameter has a range of 0-7, with the default parameter setting for GV3000E-AC024-AA-DBU being 0. When parameter P.008 is set to 0 on GV3000E-AC024-AA-DBU, GV3000E-AC024-AA-DBU is set to analog reference and digital inputs 6-8 are not used on GV3000E-AC024-AA-DBU.
What is fault code "FL" on GV3000E-AC024-AA-DBU?
Fault code "FL" on GV3000E-AC024-AA-DBU is the function loss fault. This fault occurs when function loss input on GV3000E-AC024-AA-DBU's control terminal is opened. To correct this fault on GV3000E-AC024-AA-DBU, check external interlocks at terminals 16 and 20 on GV3000E-AC024-AA-DBU.
How many power loss watts does GV3000E-AC024-AA-DBU have?
GV3000E-AC024-AA-DBU has 380 power loss watts when GV3000E-AC024-AA-DBU is operating at full load.

Reviews For GV3000E-AC024-AA-DBU

Internal Review
(5.0)

This drive has a transient suppressor for relay and contactor coils; the suppressor can help the drive avoid potential problems for AC coils with RC units and DC coils with diodes used in non-conducting directions. For more information refer to chapter three page four in the GV3000-UM060K-EN-P instruction manual. - AX Control Tech
