The Reliance Electric Bookshelf Drive GV3000E-AC005-AA-DBU has a current rating of 5.5 A. The model does not have a CE filter. The enclosure type is IP20. The US model number associated with this drive is 55ER4060, which indicates that the model is not equipped with a CE filter.



Sell Surplus: Have a GV3000E-AC005-AA-DBU to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: GV3000E-AC005-AA-DBU
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

GV3000E-AC005-AA-DBU Technical Specifications

Manufacturer Reliance Electric
Series GV3000
Part Number GV3000E-AC005-AA-DBU
Input Voltage 380-460 VAC
Enclosure IP20
Keypad/Display Built-In Keypad
Phase 3 Phase
Hz 50/60Hz
Instruction Manual D2-3426 & D2-3427
Nominal Inverter Current in V/Hz Regulation 5.5 A at 2 kHz
Nominal Motor Power at 400 VAC in V/Hz Regulation 2.2 A
US Model Number 55ER4060
European Stock Number 896.03.11

Product Description

Bookshelf Drive GV3000E-AC005-AA-DBU is part of the GV3000 series from Reliance Electric. This drive has two alternate numbers, one is described as the US model number, which is 55ER4060, and the other is the European stock number, which is 896.03.11. The US model number is the most commonly used for this bookshelf drive and is the easiest to identify the different components. The first two characters, which for this model is 55, indicate the V/Hz current rating; the current rating on this drive is 5.5 A.

The GV3000E-AC005-AA-DBU drive is part of the frequency converter family and has European approval. The last two sections on this part number indicate the inverter version. The inverter version of this model has a braking unit and DC-bus terminals. The European stock number is often associated with the inverter versions.

The second set of characters which is AC005 are indicators of the technical data. The technical data most often associated with this model is the nominal inverter current and the motor power. Depending on the regulator that the model is being used, there are different data points. For example, if the GV3000E-AC005-AA-DBU drive is used in vector mode, the inverter current is 3.8 A, with the motor power being 1.5 A at 400 VAC.

There are two manuals associated with the GV3000E-AC005-AA-DBU drive. One contains information on the US model number and European stock number; that manual is the D2-3427 Hardware Reference, Installation, and Troubleshooting Manual. The second contains information on the breakdown of the drive and how each section of the part number corresponds to the drive information that manual is labeled as GV3000-UM060K-EN-P GV3000/SE AC General Purpose and Vector Drive Instruction Manual.

Frequently Asked Questions about GV3000E-AC005-AA-DBU

How do you select diagnostics on GV3000E-AC005-AA-DBU?
To select diagnostics on GV3000E-AC005-AA-DBU, adjust parameter P.090, the Diagnostics Source Parameter. You can use this parameter to select internal information such as I/O data, network statistics, etc. for GV3000E-AC005-AA-DBU. To view the data selected in parameter P.090, choose parameter P.091, the diagnostics display parameter on GV3000E-AC005-AA-DBU.
How do you know when GV3000E-AC005-AA-DBU is too hot?
Fault code "OH" will appear on GV3000E-AC005-AA-DBU if GV3000E-AC005-AA-DBU has gone over its recommended temp. This fault is usually caused by a cooling fan failure on GV3000E-AC005-AA-DBU. To correct this fault, check the ambient temperature, the status of GV3000E-AC005-AA-DBU's cooling fan, and the clearances around GV3000E-AC005-AA-DBU.
How do you know if a fault code is fatal on GV3000E-AC005-AA-DBU?
The fatal fault codes on GV3000E-AC005-AA-DBU begin with the letter "F" followed by the code. All fault codes that are fatal will start wtih "F" and it is usually pretty easy to know if a fault code is fatal on GV3000E-AC005-AA-DBU. Common fatal fault codes on GV3000E-AC005-AA-DBU are F3, F60, and F62.
What are the input and output amps on GV3000E-AC005-AA-DBU?
GV3000E-AC005-AA-DBU has 10 input amps and GV3000E-AC005-AA-DBU has 5.5 output amps.

Reviews For GV3000E-AC005-AA-DBU

Internal Review

One of the great things about this drive is that the keypad on the front is used to operate and program the model to the user's specifications. The small display on the GV3000E-AC005-AA-DBU unit will show all of the drive parameters, error codes, and parameter values so that the user can quickly diagnose what is happening on the drive; for more information on the parameters, refer to the D2-3427 Instruction Manual. - AX Control Tech
