Drive number GV3000E-AC004-AA-DBU is one of the GV3000 bookshelf drives produced by Reliance Electric. The V/Hz current rating for this model is 3.8 A. The firmware used with the GV3000E-AC004-AA-DBU model is version 6.0 with vector and volts/hertz regulation.



Sell Surplus: Have a GV3000E-AC004-AA-DBU to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: GV3000E-AC004-AA-DBU
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

GV3000E-AC004-AA-DBU Technical Specifications

Part Number GV3000E-AC004-AA-DBU
US Model Number 38ER4060
European Stock Number 896.02.11
Series GV3000
Manufacturer Reliance Electric
Enclosure IP20
Keypad/Display Built-In Keypad
Instruction Manual D2-3426 & D2-3427
Input Voltage 380-460 VAC
Hz 60Hz
Inverter Type Braking Unit and DC-Bus Terminals
Bookshelf Drive Type Drive without CE Filter
Motor Power 1.5 kW in V/Hz mode and 1.1 in Vector Mode
Inverter Current 3.8 A in V/Hz Mode and 3.1 A in Vector Mode
Input KVA 4.8 A
Input Amps 6 A

Product Description

The GV3000 bookshelf drive number GV3000E-AC004-AA-DBU is the catalog number for the more commonly known US model number 38ER4060. There is also a European stock number for this drive which is model number 896.02.11. All of the part numbers are important in identifying the drive identification. The ER in the US model number is used for identifying what type of bookshelf drive it is either with or without a CE filter this model does not have a CE filter. The current rating for this model is 3.8 amperes which is denoted by the 38 at the beginning of the US model number.

When assessing the GV3000E-AC004-AA-DBU model number you will notice that there are four sections. All of the sections are useful as it fully describes the drive, for example, the E indicates the drive has European approval, the AA indicates the enclosure type which is IP20, the DBU indicates that the model has a breaking unit and the AC004 will help indicate the full technical data. Some of the technical data includes the inverter current and motor power. Since there are two regulator types the values for the inverter current and motor power differ, for example, the vector regulator will have the motor power running at 1.1 kW and the inverter current running at 3.8 amperes.

The GV3000E-AC004-AA-DBU drive has a line input current and branch circuit protection fuses. The AC-input current with the choke is 5 amperes, with the external fuse on the drive being at a maximum of 25 amperes, and a nominal of 6 amperes.

Frequently Asked Questions about GV3000E-AC004-AA-DBU

Which input is for starting GV3000E-AC004-AA-DBU?
Digital input 1 on GV3000E-AC004-AA-DBU is the input for starting GV3000E-AC004-AA-DBU. Digital input 1 is located in terminal 24 on GV3000E-AC004-AA-DBU.
What does the "FL" fault code mean on GV3000E-AC004-AA-DBU?
The "FL" fault code on GV3000E-AC004-AA-DBU indicates a function loss on GV3000E-AC004-AA-DBU. When "FL" appears on GV3000E-AC004-AA-DBU, the function loss input on GV3000E-AC004-AA-DBU's control terminal has been opened. To correct this fault, check external interlocks at terminals 16 and 20 on GV3000E-AC004-AA-DBU.
What is the maximum humidity GV3000E-AC004-AA-DBU can hold up to?
The maximum humidity GV3000E-AC004-AA-DBU can stand up to is 50% at 40 degrees Celsius unlimited.
Where can I find the manuals for GV3000E-AC004-AA-DBU?
We have the manuals for GV3000E-AC004-AA-DBU on file for you. We can send you a link to both manuals for GV3000E-AC004-AA-DBU. Manual D2-3426 is the software manual for GV3000E-AC004-AA-DBU and Manual D2-3427 is the hardware manual for GV3000E-AC004-AA-DBU.

Reviews For GV3000E-AC004-AA-DBU

Internal Review

During the operation of the GV3000E-AC004-AA-DBU drive the model could potentially reset automatically. One issue with this auto-reset parameter is that it will be disabled when the vector regulator self-tunes and when the V/Hz regulator goes through an identification procedure. - AX Control Tech
