GV3000E-AC003-AA-DBU

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (4)
  • Click a star to rate this product
The GV3000E-AC003-AA-DBU drive is one of the bookshelf drives produced by Reliance Electric without a CE filter. The current rating on this drive is 3.1 A. The motor power for this model when operating in vector mode is 0.75 kW, with a nominal inverter current of 2.1 A.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a GV3000E-AC003-AA-DBU to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: GV3000E-AC003-AA-DBU
  • SKU: GV3000EAC003AADBURE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

GV3000E-AC003-AA-DBU Technical Specifications

Part Number GV3000E-AC003-AA-DBU
US Model Number 31ER4060
European Stock Number 896.01.11
Series GV3000
Manufacturer Reliance Electric
Enclosure IP20
Keypad/Display Built-In Keypad
Instruction Manual D2-3426 & D2-3427
Phase 3 Phase
Input Voltage 380-460 VAC
Inverter Type Basic Version with Braking Unit and DC-Bus Terminals
HP 1 HP
kW 4.5kW
Hz 50/60Hz
Motor Power in V/Hz Mode 1.1 kW
Inverter Current in V/Hz Mode 3.1 A
Input Amps 5 A
Input KVA 4.0 KVA

About the GV3000E-AC003-AA-DBU

Model number GV3000E-AC003-AA-DBU is a bookshelf drive created by Reliance Electric for the GV3000 series. This drive will run on a volts/hertz current rating of 3.1 A with an input amperage of 5 A. The power loss wattage at full load is 60 A. Some of the GV3000 bookshelf models come with a CE filter; this model is one of the drives that does not have the CE filter.

There are two alternate part numbers associated with this drive, one is known as the European stock number, and the other is known as the US model number. The US model that correlates with the GV3000E-AC003-AA-DBU drive is 31ER4060, and the European stock number is 896.01.11. A full breakdown of the part number for the US and European models can be found in the D2-3427 GV3000/SE Bookshelf Drive Instruction Manual in chapter two on the first and second pages of the chapter.

The GV3000E-AC003-AA-DBU model has an inverter current and motor power depending on the regulator mode used, which can be vector or volts/hertz regulation modes; there are different values associated with the motor power and inverter currents. When the drive is working in vector mode the nominal motor power at approximately 400 VAC is 0.75 kW, whereas the inverter current at 2 kHz is 2.1 A.

There are two different inverter versions associated with GV3000E-AC003 models. The GV3000E-AC003-AA-DBU drive is the most basic inverter version only equipped with DC-bus terminals and a braking unit. For more information on the correlation between this drive and the inverter components refer to the GV3000-UM060K-EN-P Instruction Manual.

Frequently Asked Questions about GV3000E-AC003-AA-DBU

What is the turn-on and turn-off voltage on GV3000E-AC003-AA-DBU?
GV3000E-AC003-AA-DBU has a 750V turn-on voltage. GV3000E-AC003-AA-DBU has a 720V turn-off voltage.
What does parameter U.025 do on GV3000E-AC003-AA-DBU?
Parameter U.025 on GV3000E-AC003-AA-DBU is the zero speed hold time parameter. This parameter on GV3000E-AC003-AA-DBU selects the amount of time for which zero speed is held at the end of a ramp stop sequence on GV3000E-AC003-AA-DBU. GV3000E-AC003-AA-DBU has this parameter default set to 0.0 but the parameter has a range of 0.0 to 655.0 seconds. This parameter on GV3000E-AC003-AA-DBU is a tunable parameter.
What is GV3000E-AC003-AA-DBU's input KVA?
GV3000E-AC003-AA-DBU has a 4.0 input KVA.
What are the power loss watts on GV3000E-AC003-AA-DBU?
The power loss watts on GV3000E-AC003-AA-DBU are 60 when GV3000E-AC003-AA-DBU is at full load.
Where can I find the manuals for GV3000E-AC003-AA-DBU?
We can send you a link to both the software manual and the hardware manual for GV3000E-AC003-AA-DBU. The software manual for GV3000E-AC003-AA-DBU is Manual D2-3426 and the hardware manual for GV3000E-AC003-AA-DBU is Manual D2-3427. Each manual is a Reliance manual and we have links to each manual to send you for GV3000E-AC003-AA-DBU.

Reviews For GV3000E-AC003-AA-DBU

Internal Review
(5.0)

The GV3000E-AC003-AA-DBU drive is an excellent purchase if the user requires a drive that has an AC-line distribution capacity of 10 kA. This drive also comes with line input current and branch circuit protection fuses that can be used with and without a choke. - AX Control Tech
