The 896.14.91 is a Reliance Electric 50HP/75HP GV3000/SE Drive.

AVAILABILITY:

IN STOCK
SHIPS TODAY

2 Year Warranty: Learn More
Sell Surplus: Have a 896.14.91 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 896.14.91
  • SKU: 896.14.91RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

896.14.91

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
The 896.14.91 is a Reliance Electric 50HP/75HP GV3000/SE Drive.

AVAILABILITY:

IN STOCK
SHIPS TODAY

2 Year Warranty: Learn More
Sell Surplus: Have a 896.14.91 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 896.14.91
  • SKU: 896.14.91RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

896.14.91 Technical Specifications

Enclosure NEMA 1
HP 75 HP
Hz 50/60Hz
Input Voltage 380-460 VAC
Instruction Manual D2-3359 & D2-3360
Keypad/Display Built-In Keypad
Manufacturer Reliance Electric
Part Number 896.14.91
Phase 3 Phase
Series GV3000

Product Description

The 896.14.91 is a Reliance Electric 50HP (vector) or 75HP (V/Hz) GV3000/SE Drive. ABB and Baldor Reliance may have also sold this drive under their manufacturing names at one point. This drive can also be found under the alternative part number 50T4150.

The 896.14.91 is in a very large NEMA 1 style chassis. It has circulation air vents on its sides and front. The built-in keypad is located just below the air vents on the front of the chassis. Slightly below and to the left of the keypad, is a slot where the operator can access an RS-232 serial port on the regulator card. On the bottom side of the chassis are two external fan assemblies that help to regulate airflow to the internal components of the drive. There is also an internal fan assembly in the chassis that helps to keep the air moving.

The keypad on the 896.14.91 has several components that are standard for the GV3000 series of drives. There is a display panel in the top left corner that shows the LED 7-segment 4-digit indicator located on the regulator. Just below that are 14 LED indicator lights. These are labeled speed, program, running, password, volts, reverse, remote, torque, amps, forward, jog, Kw, HZ, and auto. There is a start and stop/reverse button just below the LEDs on the left bottom corner of the keypad. On the right-hand side of the keypad are an enter key, a program key, a run/jog key, an auto/man key, a forward/reverse key, and two arrow keys.

Frequently Asked Questions about 896.14.91

What terminals does the AC input power connect to on 896.14.91?
On 896.14.91, connect the AC input power leads to terminals 1L1, 1L2, and 1L3 on 896.14.91's terminal strip. These terminals on 896.14.91 are also known as U, V, W. The maximum tightening torque when tightening the AC input power to 896.14.91 should be 10 newton-meters (7.4 ft-lb).
How many output amps does 896.14.91 have?
When 896.14.91 is at a carrier frequency of 2 kHz, 896.14.91 has 90 output amps. When 896.14.91 is at 4 kHz, 896.14.91 has 72 output amps. When 896.14.91 is at 8 kHz, 896.14.91 has 54 output amps.
How do I get the manuals for 896.14.91?
We can send you links to the 896.14.91 manuals. The manuals for 896.14.91 are the GV3000 NEMA style software and hardware manuals, Manuals D2-3359 and D2-3360. We're happy to send the manuals for 896.14.91 right to you and the manuals will help you greatly with 896.14.91.
What is the analog speed reference resolution on a reliance 896.14.91?
The analog speed reference resolution on 896.14.91 is 1/1024 (10 bits) or 0.1%.
