Reliance Electric's 896.08.31 bookshelf drive is from the GV3000 series. This model has a CE/RFI filter and will operate on a voltage range of 380 to 460 VAC. The V/Hz current rating of the 896.08.31 drive is 24.0 amperes.



Sell Surplus: Have a 896.08.31 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 896.08.31
  • SKU: 896.08.31RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

896.08.31 Technical Specifications

Part Number 896.08.31
Catalog Number GV3000E-AC024-AA-DBU-RFI
US Model Number 240ET4060
Manufacturer Reliance Electric
Series GV3000
Keypad/Display Built-In Keypad
Instruction Manual D2-3426 & D2-3427
Enclosure IP20
Dimensions Width A 7.68" x Height 14.72" x Width C 2.40" x Depth 7.87" x Mounting Height 16.61"
Input Voltage 380-460 VAC
Phase 3 Phase
Hz 50/60Hz
Current Rating 24.0 A
Inverter Type DC Bus Terminal, Braking Resistor Circuit, and Built-In CE Filter
Input KVA 19.9 KVA
Input Amps 25 A
Power Loss Watts (Full Load) 380

About the 896.08.31

Reliance Electric’s GV3000 drive 896.08.31 is the European stock number for the 240ET4060 bookshelf drive. This drive will operate on a Volts/Hertz current rating of 24.0 A. The voltage range that this model operates on is 380 to 460 VAC. The enclosure type associated with this model is an IP20 enclosure IP20 enclosures are not water-tight but can protect the drive against any solid object twelve millimeters or more. When referring to the US model number, the ER in the middle indicates that the bookshelf drive is equipped with a CE filter.

As mentioned above, the 896.08.31 drive is the European stock number, but there is another number that this drive is often referred to as, which is catalog number GV3000E-AC024-AA-DBU-RFI. The catalog number gives an in-depth look into what type of inverter the drive will use which in this case is an inverter with DC-bus terminals, an RFI filter, and a braking unit. When connecting the braking unit and braking resistor, the cable must be no longer than 2.5 meters as it could cause potential errors when running the two together. The maximum continuous braking current for the 896.08.31 drive is 15 A rms.

When mounting the 896.08.31 drive, it is vital to the performance of the unit that all airflow clearances are met. If the airflow clearances are not met, the drive could potentially overheat and must be shut down before any errors occur that could hinder the performance of the drive. The minimum clearances for the drive can be found in chapter three of the D2-3427-E GV3000/SE AC Bookshelf Drive Hardware Reference, Installation, and Troubleshooting Manual.

Frequently Asked Questions about 896.08.31

What is the torque linearity on 896.08.31?
The torque linearity on 896.08.31 is +3% with optimal parameter setting. The parameter to adjust the torque linearity is parameter U.005.
Does 896.08.31 have a fan?
Yes, 896.08.31 has two fans. The part numbers for the fans on 896.08.31 are: 922.67.05 and 922.68.05.
Where can I get help with troubleshooting a reliance 896.08.31?
We can help with some 896.08.31 troubleshooting issues. The hardware manual for 896.08.31 is also a great place to look for troubleshooting issues. Chapter 10 in the hardware manual for 896.08.31 is dedicated to troubleshooting GV3000 bookshelf drives. The troubleshooting section in the manual includes information on test equipment needed for troubleshooting, alarms and faults on 896.08.31, verification of 896.08.31's DC bus capacitors, checking 896.08.31 while power is off, checking 896.08.31's cooling fans, and replacement parts for 896.08.31. The manual is Manual D2-3427 and we can send you the copy of the manual if needed.
How do I find the manuals for 896.08.31?
We can send you the manuals for 896.08.31. We have copies of both the software manual for 896.08.31, Manual D2-3426, and the hardware manual for 896.08.31, Manual D2-3427. Both manuals will be helpful for 896.08.31.

Reviews For 896.08.31

Internal Review

Drive number 896.08.31 has two fans which will help with the cooling of the drive. Occasionally these fans will stop working due to their limited lifetime. If during the operation of the 896.08.31 drive, the fans go out they need to be replaced immediately to keep the drive from malfunctioning due to the possibility of overheating. Overheating on the drive can not only cause issues with the drive itself but could potentially injure the user as well. - AX Control Lead Technician
