10HP NEMA 1 10V4160 AC Drive



Sell Surplus: Have a 896.07.80 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 896.07.80
  • SKU: 896.07.80RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

896.07.80 Technical Specifications

Manufacturer Reliance Electric
Series GV3000
Part Number 896.07.80
HP 10 HP
Input Voltage 380-460 VAC
Enclosure Type 1/IP20
Keypad/Display Built-In Keypad
Phase 3 Phase
kW 7.5kW
Hz 50/60Hz
Instruction Manual D2-3359 & D2-3360

Product Description

The 896.07.80, which can also be found under the part number 10V4160, is a 10HP GV3000/SE Drive. It was initially made by Reliance Electric and later probably mass-produced by ABB or Baldor Reliance.

The 896.07.80 is version 6.04 of this drive to be produced. It is a 380-460 VAC 50/60 HZ 3-Phase PWM (or pulse-width-modulated) drive. It has the power to flip-flop between vector and standard V/Hz regulation.  It has an input of 16.8A and 13.4KVA. It has an output of 14.2A at 2, 4, or 8 kHz. This drive is 20 lbs. and 11.05” wide, 13.32” tall, and 7.87” thick.

This drive is protected by a NEMA 1/IP20 style enclosure. It is not meant for outside operations because it has air vents on its bottom and is not drip/dust-tight. It has a small flap on the front slightly below and to the left of the keypad. This flap grants the user access to an RS-232 port that is on the regulator PCB. On the backside of the enclosure are a pair of exposed fans that help to facilitate air flowing to the internal circuitry of the drive.

The keypad on the 896.07.80 is built-in and comes standard on all version 6.04 GE3000-SE models. It has a display port on its top left corner that allows the user to see the alpha-numeric 7-segment 4-digit LED display panel that is located on the regulator board. Below that are 14 red LED indicators that show the drive status and operating mode of the drive.  There are 9 keys on the keypad.

Frequently Asked Questions about 896.07.80

How much input KVA does 896.07.80 have?
896.07.80 has 13.4 KVA input.
What does fault code "EC" indicate on 896.07.80?
Fault code "EC" on 896.07.80 indicates an earth current failure or ground fault. This fault on 896.07.80 is caused by unintentional grounding of the output on 896.07.80. To correct the fault, check isolation between ground and output terminals on 896.07.80. This fault on 896.07.80 could be caused by possible leakage or current sensor defects.
How do I enable the self-tuning procedure on 896.07.80?
To enable 896.07.80's self-tuning procedure, turn parameter U.008, the torque self-tune enable parameter, on. For FVC operation on 896.07.80, this parameter determines the encoder PPR selection for parameter U.001. For FVC and SVC operation on 896.07.80, this parameter adjustment also determines the value for parameter U.006, the magnetizing current parameter.
Where can I find the manuals for 896.07.80?
We'd be happy to send you the manuals for 896.07.80. The manuals for 896.07.80 are Manuals D2-3359 and D2-3360, the GV3000 NEMA style software and hardware manuals.
