896.05.70

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (4)
  • Click a star to rate this product
The GV3000 Drive 896.05.70 is one of the AC drives. This model will operate on 5 HP and can be used in vector or V/Hz regulator modes. The US model number associated with the 896.05.70 drive is 5V4460. The drive has a NEMA 4X/12 enclosure rating.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 896.05.70 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 896.05.70
  • SKU: 896.05.70RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

896.05.70 Technical Specifications

Part Number 896.05.70
Catalog Number GV3000U-AC009-AF-DBT
Series GV3000
Manufacturer Reliance Electric
Enclosure NEMA 4X/IP54 or NEMA 12/IP52
Instruction Manual D2-3359 & D2-3360
Keypad/Display Built-In Keypad
Input Voltage 380-460 VAC
kW 4.0 kW
Hz 50/60Hz
HP 5 HP
Amp Rated Current 32 Amps
Inverter Current 8.2
Phase 3 Phase
Power Loss Watts (Full Load) 180

Product Description

Produced by Reliance Electric for the GV3000 series, the 896.05.70 model is one of the AC drives. This drive will operate on 5 HP and has an alternate part number that directly correlates with the horsepower on the drive. More commonly referred to as the US model number, the 5V4460 drive is just one of the alternate part numbers. The other part number is referred to as the GV3000 catalog number, this number is GV3000U-AC009-AF-DBT. The catalog number helps indicate what the typical motor power will be when the drive is being used in volts/hertz or regulator modes, occasionally the power of the motors will be different but in this case, the power is the same sitting at 4 kW.

There are many different inputs including input amps and input KVA (kilovolt-amperage), as well as outputs amps. For the 896.05.70 drive, there are three output amps carrier frequencies associated with the model, these are output amps at 2, 4, and 8 kHz; once again sometime the output will be different values but the values at each output carrier frequency, in this case, are all 8.2. The input amperage for this model is 9.9 A, with the KVA the input is 7.9 A.

There are two different manuals that are best suited for guiding the user on how the 896.05.70 operates, must be installed, etc. The first of the two manuals, which is the GV3000-UM060K-EN-P GV3000/SE AC General Purpose and Vector Drive Instruction Manual lists all of the cross reference parts, whereas the D2-3360-5 GV300/SE AC Drive Hardware Reference, Installation, and Troubleshooting Manual is best used for finding out fault codes, alarm codes, and how to fix them.

Frequently Asked Questions about 896.05.70

What does the "I-Ac" fault code error mean on 896.05.70?
"I-Ac" is actually an alarm code on 896.05.70 rather than a fault code. Alarm codes differ from fault codes as they only appear on 896.05.70 as long as the problem exists on 896.05.70. "I-Ac" is the aram for an active V/Hz identification procedure. This is not really a fault or a problem on 896.05.70, "I-Ac" simply indicates that you need to wait for the identifcation procedure to finish on 896.05.70.
Where are the status relay connections for 896.05.70?
The status relays connect at terminals 28-31 on 896.05.70's terminal strip.
How big is 896.05.70?
896.05.70 is 8.75 by 11.05 inches. 896.05.70 is 7.87 inches deep. 896.05.70 weighs 14lbs.
How much clearance should there be around a reliance 896.05.70?
There should be at least 4 inches of clearance around each side of 896.05.70. This means there should be a 4 inch clearance between the front of 896.05.70, the back of 896.05.70, and the left and right of 896.05.70.

Reviews For 896.05.70

Internal Review
(5.0)

Drive number 896.05.70 is the best model to use if the user requires a drive that has DC bus terminals as well as two different enclosure ratings of IP52/IP54. - AX Control Technician

Repair Services For 896.05.70

Type Lead Time Price Action
Repair Service 1-2 weeks $1128

Our highly skilled technicians can repair your 896.05.70. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
