Reliance Electrics' 50/60Hz GV3000 series 896.05.11 drive is a 5 HP 3-phase drive with an input voltage rating of 380-460 VAC and an IP20 enclosure.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 896.05.11 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 896.05.11
  • SKU: 896.05.11RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

896.05.11 Technical Specifications

Manufacturer Reliance Electric
Series GV3000
Part Number 896.05.11
HP 5 HP
Input Voltage 380-460 VAC
Enclosure IP20
Keypad/Display Built-In Keypad
Phase 3 Phase
Hz 50/60Hz
Instruction Manual D2-3426 & D2-3427

About the 896.05.11

The 896.05.11 model is a bookshelf AC drive that Reliance Electric made so that it could be included inside of the GV3000 product line. The 896.05.11 bookshelf AC drive is not being produced. Despite this situation, the 896.05.11 bookshelf AC drive may still be found inside of AX Control’s inventory. If you would like to make sure that this product is available in AX Control’s inventory, you can utilize our website’s tools.

The “bookshelf” drives in the GV3000 product line are significantly smaller in size than the regular-sized drives in the series. This does mean that these drives will have lower ratings for the inputs and outputs than the normal-sized drives. As a result, the bookshelf drives are better suited for certain low-power applications.

The 896.05.11 bookshelf AC drive possesses the AC input current rating of 13 A and is not outfitted with a choke. The external fuse for the 896.05.11 bookshelf AC drive has a nominal rating of 16 A and a maximum rating of 25 A.

The input for the 896.05.11 bookshelf AC drive possesses the voltage range of 380 thru 460 VAC, a kiloVolt-Amps rating of 10.4, and an Amps rating of 13 A. The output Amps when the drive is operating at V/Hz regulation is 8.5 A at both 2 kHz and 4 kHz and 5.5 A at 8 kHz. The output Amps when the drive is operating at Vector regulation is 6.7 A at both 2 kHz and 4 kHz and 5.0 A at 8 kHz.

Frequently Asked Questions about 896.05.11

What are the input amps for 896.05.11?
896.05.11 has 13 input amps.
Which parameter controls speed of 896.05.11?
There are two main parameters that control speed of 896.05.11. Parameter P.004 is the maximum speed parameter on 896.05.11. Parameter P.003 on 896.05.11 is the minimum speed parameter. There are several other parameters on 896.05.11 that deal with time but these two parameters in particular, parameter P.004 and parameter P.003, deal with speed of 896.05.11.
What is the voltage of the analog output terminals on 896.05.11?
The analog outputs on 896.05.11 are located in terminals 10 and 11 on 896.05.11. The analog outputs on 896.05.11 have a 0-10 VDC output voltage.
What are the two manuals for 896.05.11?
There are two main manuals for 896.05.11. Manual D2-3426 is the GV3000/SE AC General Purpose and Vector Duty Bookshelf Drive Software Start-Up and Reference Manual, aka the software manual for 896.05.11. Manual D2-3427 is the GV3000/SE AC Bookshelf Drive Hardware Reference, Installation, and Troubleshooting Manual, aka the hardware manual for 896.05.11. Both manuals are great for 896.05.11 but each manual offers a little something different about 896.05.11. Each manual will help you with 896.05.11 in a different way, but it's important to read both manuals.

Reviews For 896.05.11

Internal Review
(5.0)

Currently not manufactured in the United States as part of a Reliance Electric legacy series but proudly offered through AXcontrol, the GV3000 series' 895.05.11 drive is a convenient indoor model; rated as a "bookshelf-style" automated drive. The small size of this drive is somewhat indicative of this drive's performance characteristics; this legacy model specifically features a horsepower rating of 5 HP, and only demands a IP20 indoor chassis. - AX Control Lead Technician
