Reliance Electric GV3000 Bookshelf Drive 896.03.31 operates at a current rating of 5.5 A when in volts/hertz. The alternate number for this drive is 55ET4060. The power loss watts at full load that this drive will experience is 100. The input KVA for the 896.03.31 model is 6.4.
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 896.03.31 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 896.03.31
  • SKU: RE-9570
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

896.03.31 Technical Specifications

Part Number 896.03.31
Catalog Number GV3000E-AC005-AA-DBU-RFI
US-Model-Number 55ET4060
Series GV3000
Enclosure IP20
Instruction Manual D2-3426 & D2-3427
Keypad/Display Built-In Keypad
Manufacturer Reliance Electric
Input Voltage 380-460 VAC
Model Version DC-Bus Terminals, Braking Unit, and RFI Filter
Replacement Inverter Type Type B
V/Hz Current Rating 5.5 A
Output Amps in V/Hz Mode at 2 kHz 5.5
Motor Power in Vector Mode 3.8
Phase 3 Phase
HP 55 HP
Hz 60Hz

About the 896.03.31

The 896.03.31 drive is a bookshelf drive manufactured by Reliance Electric as part of the GV3000 series. This model is commonly known as the European stock number for the 55ET4060 part number as such it is known that the model will operate on a current rating of 5.5 amps. The 896.03.31 drive has an IP20 enclosure thus it is able to be protected from objects that are greater than 12 mm. This drive is also commonly known as a GV3000/SE Bookshelf Drive with a CE filter.

There is another alternate part number that the 896.03.31 drive is often referred to as which is GV3000E-AC005-AA-DBU-RFI. This part number refers to the converter and the corresponding inverter versions. For this model, the inverter version has DC-bus terminals, an RFI filter, and a braking unit. There is also a motor that corresponds with the 896.03.31 drive, in this case, the drive has two different motor powers depending on the regulator version being used for vector regulation the power of the model is a nominal 1.5 at 400 VAC whereas the motor power for the drive when in volts/hertz regulation the power is 2.2 also at 400 VAC.

When using the 896.03.31 after mounting it is vital to the operation that all airflow clearances have been met. The minimum clearances for the drives are no larger than 4 inches. The clearance between the bookshelf drives is a quarter of an inch. For all clearances refer to chapter three of the GV3000/SE AC Bookshelf Drive Hardware Reference, Installation, and Troubleshooting Manual for more detailed information.

Frequently Asked Questions about 896.03.31

How much clearance should there be from the top and bottom of 896.03.31?
Above and below 896.03.31, there should be a minimum clearance of 4 inches.
What terminals do ground wiring connect to on 896.03.31?
Ground wiring is connected to terminals L1, L2, L3, and PE on 896.03.31. You can also connect AC input power wiring to these terminals on 896.03.31. The wire size for both types of wiring on 896.03.31 should be 6 AWG.
What is the recommended external fuse for 896.03.31?
For 896.03.31, a 16 amp branch circuit protection fuse is recommended for AC line input. For DC bus input on 896.03.31, a semiconductor protection fuse is recommended.
Which manual will help with wiring a Reliance 896.03.31?
The manual that will help with wiring your 896.03.31 is Manual D2-3427, the Bookshelf Hardware Manual for 896.03.31. This manual has an entire chapter dedicated to wiring and the manual will answer any questions you may have on wiring a 896.03.31. The manual is an original Reliance manual and we can send you the manual.

Reviews For 896.03.31

Internal Review
(5.0)

Model number 896.03.31 is best used in indoor applications where the user does not need to go inside the enclosure at any point to reach communication ports. All available communications can be performed from outside of the drive. - AX Control Technician
