GV3000/SE AC Drive 896.02.80 from Reliance Electric operates on 2 HP in V/Hz and Vector regulators. The US model number associated with this model is 2V4160. The 896.03.8 model is the DC-bus version of the GV3000U-AC004 drive. The rated current on this drive is 32 amps.



Sell Surplus: Have a 896.02.80 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 896.02.80
  • SKU: 896.02.80RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

896.02.80 Technical Specifications

Part Number 896.02.80
GV3000 Catalog Number GV3000U-AC004-AA-DBT
US-Model-Number 2V4160
Series GV3000
Manufacturer Reliance Electric
Instruction Manual D2-3359 & D2-3360
Regulator Type Vector and V/Hz Regulator Version 6.0 Firmware
Input Voltage 380-460 VAC
Keypad/Display Built-In Keypad
Enclosure Type 1/IP20
Weight Approx. 14 lbs
Phase 3 Phase
Hz 50/60Hz
kW 1.5kW
Input KVA 5.1
Output Amps at 8 kHz 5.3 A

Product Description

The GV3000 Drive 896.02.80 was produced by Reliance Electric as part of the GV3000 series. The model is considered an AC power drive. Two other model numbers are also used when referring to the 896.02.80 drive. These other two numbers are known as the catalog number and the US-Model-Number. The US-Model-Number is 2V4160 whereas the catalog number is GV3000U-AC004-AA-DBT. The catalog number fully describes the GV3000 drive. Some examples of the corresponding description and the characters in the part number are AA which indicates the enclosure type, DBT indicates the DC-bus terminals, and more.

When the 896.02.80 drive is referred to as 2V4160 it is easy to distinguish what each of the characters means within the part number, for example, the 2 indicates that the drive operates on 2 HP, the 4 indicates the voltage range which is 380 V to 460 V, and the 1 indicates the specific enclosure type which is NEMA 1. The NEMA 1 enclosure is vented and has a communication door that can be used to easily access the communication ports inside the enclosure without having to fully remove the cover of the drive.

Two regulator versions can be used with the 896.02.80 drive; the vector regulator is primarily used as a high-performance variable speed AC controller, with the V/Hz regulator being used for outputting frequencies and the appropriate motor voltages when operating in open loop control. The vector regulator uses closed-speed feedback or loop-flux vector control operation.

Frequently Asked Questions about 896.02.80

How big is 896.02.80?
896.02.80 is 8.75 by 11.05 inches at its widest and tallest point. 896.02.80 has a depth of 7.87 inches. 896.02.80 weighs 14lbs.
What terminals connect to output wiring on 896.02.80?
Terminals U/T1, V/T2, and W/T3 are the terminals that connect output power to 896.02.80. Output power wiring for 896.02.80 should have a 12 AWG, 3 mm^2 wire size.
How much input KVA does 896.02.80 have?
896.02.80 has 3.3 KVA input.
Which manual is which for 896.02.80?
Manual D2-3359 is the software manual for 896.02.80. This manual for 896.02.80 is the Reliance Software Start-Up and Reference Manual for 896.02.80. Manual D2-3360 is the hardware manual for 896.02.80. This manual is the GV3000 Hardware Reference, Installation, and Troubleshooting Manual for 896.02.80.

Reviews For 896.02.80

Internal Review

The 896.02.80 drive is one of the drives within the GV3000 series that has DC-Bus terminals and an IP20/NEMA 1 enclosure type. The model is excellently rated for use in indoor applications and has a communication access door to easily access the ports located within the enclosure. - AX Control Technician
