803624-28C Technical Specifications

Manufacturer Reliance Electric
Part Number 803624-28C
Series GV3000

Product Description

The 803624-28C is a Printed Circuit Board made by Reliance Electric.  It is possible that this card was also produced by ABB and Baldor Reliance. This board is no longer being supported by Reliance or other companies that may have sold it and it may be difficult to locate. AX Control makes every attempt to keep it in stock though as a refurbished or new surplus part.

The 803624-28C is a small Capacitor printed circuit board that goes onto a GV3000-VTAC 7/SE drive. This board is 10 inches long and weighs a little over half a pound. It is considered to be a replacement part for a 1-5HP drive controller. It may not be used in controllers that have a high HP rating; a different type of capacitor is needed for those controllers. Only one of these boards is needed in the controller. This board is typically mounted inside of the controller and is located on the left-hand side of the drive. It is near the current feedback board that is behind the regulator board and the keypad.

The 803624-28C has a few components on its green printed board. It consists of a total of 4 electrolytic capacitors, two thermistors, two resistors, and two sets of pin connectors.

For more information about the 803624-28C, please read the Reliance user’s guide D2-3340. It is important to remember to wear an anti-static wristband when you are installing or removing any of the internal components in a GV300 drive to prevent any type of circuit damage or drive irregularities.

Frequently Asked Questions about 803624-28C

What type of product is 803624-28C?
803624-28C is a Reliance capacitor printed circuit board for GV3000 - VTAC 7 drives.
How big is 803624-28C?
803624-28C is about 10 inches long.
