Reliance Electric GV-3000 GV3000/SE 3 HP AC Motor Drive.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 3V4160 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 3V4160
  • SKU: 3V4160RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

3V4160 Technical Specifications

Manufacturer Reliance Electric
Series GV3000
Part Number 3V4160
HP 3 HP
Input Voltage 380-460 VAC
Enclosure Type 1/IP20
Keypad/Display Built-In Keypad
Phase 3 Phase
kW 2.2kW
Hz 50/60Hz
Instruction Manual D2-3359 & D2-3360

Product Description

The 3V4160 unit is an AC drive that was made for the GV3000 series, which was produced by Reliance Electric. The 3V4160 AC drive is no longer being produced by Reliance Electric, but AX Control may still have it in stock at this time. You can verify whether or not the 3V4160 AC drive is in stock with us currently by searching on our website or by contacting us using our email address or our phone number.

The 3V4160 AC drive is a large device that has a small user interface area. The top left of the 3V4160 AC drive has a small, rectangular display. Just below that, there are numerous LED indicators split into two rows of seven. On the left side, these LED indicators are labeled as follows from top to bottom: “SPEED,” “VOLTS,” “AMPS,” “Hz,” “Kw,” “TORQUE,” and “Password.” On the right side, these LED indicators are labeled as follows from top to bottom: “RUNNING,” “REMOTE,” “JOG,” “AUTO,” “FORWARD,” “REVERSE,” and “PROGRAM.” In addition to that, there are many buttons on the interface area. Below the LED indicators, there is a button labeled “STOP/RESET” and another button labeled “START.” On the right side, there are white buttons which are labeled as follows: “AUTO/MAN,” “Forward/Reverse,” “PROGRAM,” “RUN/JOG,” and “ENTER.” The top two buttons are up and down arrow buttons.

The 3V4160 AC drive has an input kVA rating of 5.1 kVa and an input Amps rating of 6.4 A. The output Amps at 2 kHz, 4 kHz, and 8 kHz is 5.3 A. At full load, the power loss Watts is 140 W.

Frequently Asked Questions about 3V4160

What does the "LU" fault code mean on 3V4160?
When the "LU" fault code appears on the display of 3V4160, a low DC bus voltage fault has occurred on 3V4160. This fault can be caused by a line dip that is too long on 3V4160 or the fault can be caused by 3V4160 having defective input rectifier diodes. To correct this fault on 3V4160, it may be necessary to add a transformer. You also may need to replace the diode set on 3V4160 to correct the fault.
Where can I find a list of parameters on 3V4160?
You can find a list of parameters for 3V4160 in Appendix A in the software manual for 3V4160, Manual D2-3359. Appedix A in the manual for 3V4160 provides an alphabetical list of parameters. The appendix in the manual first lists first menu general parameters, then second menu general parameters, followed by second menu volts/hertz parameters, second menu vector parameters, and second menu RMI parameters on 3V4160. Appendix B in the manual allows you to record adjusted settings on parameters on your 3V4160, and earlier in the manual, you will find full descriptions of the parameters on 3V4160.
What is the input KVA on 3V4160?
3V4160 has 5.1 KVA input.
Is 3V4160 always at 3HP?
Yes, 3V4160 is always at 3 horsepower whether 3V4160 is at V/Hz or Vector regulation.

Repair Services For 3V4160

Type Lead Time Price Action
Repair Service 1-2 weeks $1647

Our highly skilled technicians can repair your 3V4160. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
