Reliance GV3000 to Automax Communication Network Card

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 2AX3000 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 2AX3000
  • SKU: 2AX3000RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

2AX3000 Technical Specifications

Manufacturer Reliance Electric
Series GV3000
Part Number 2AX3000
Instruction Manual D2-3308

About the 2AX3000

The 2AX3000 is a Network Card Kit that was created by Reliance Electric for their GV3000 series controllers. This PCB may have also been sold by Baldor Reliance and ABB at some point. None of these companies still maintain the 2AX3000, but AX Control does make an effort to keep it in stock.

The 2AX3000 is an AutoMax Network Communications Option PCB. This board has the capability to facilitate the monitoring and operation of the drive controller over the AutoMax network. This kit does come with a Network Drop Cable (2NC3000). This cable is used to connect the controller to a passive tap. It uses the terminal strip on the board to do this. This option board turns the controller into a slave drop on the AutoMax network.

The 2AX3000 is mounted in the interior of the controller and connects directly to a regulator board using a ribbon cable that is located on the left side of the board.  There is a 26-pin ribbon cable that is also connected to the board that leads to a current feedback board. The current feedback board is located below the keypad on the right side. There are two jumpers below that ribbon cable and below that is the terminal connection that goes to the passive tap. This board is mounted directly behind the regulator board and connects to the right side of the mounting bracket on the keypad.

Please be sure to read the Reliance instruction manual D2-3308 before installing this board into your controller. It is also important to make sure that you wear an anti-static wristband when handling this board or any other internal component for your controller.

Frequently Asked Questions about 2AX3000

What type of product is 2AX3000?
2AX3000 is an AutoMax Network Communication Option Board used with GV3000/SE AC drives. 2AX3000 allows a GV3000 drive to be operated and monitored over the AutoMax network. 2AX3000 connects to a GV3000 with a Network Drop Cable (M/N 2NC3000) and 2AX3000 mounts inside a GV3000 drive connects to the drive's Regulator board using a ribbon cable. 2AX3000 is poweded by the GV3000 drive's power supply.
What jumpers does 2AX3000 have?
2AX3000 is shipped with jumpers J4 and J5, which connect to pins 1 and 2. You must change the position of the jumpers to connect pins 2 and 3 before installing 2AX3000 for certain GV3000 drives. To see which drives 2AX3000's jumpers need to be changed on, view Section 2.1 in the 2AX3000 manual, Manual D2-3308.
What is the manual for 2AX3000?
The manual for 2AX3000 is the AutoMax Network Communications Option Board for use with GV3000/SE AC Drives Instruction Manual, Manual D2-3308. While the option board, 2AX3000, uses the AutoMax network, the manual focuses more on GV3000 as 2AX3000 connects to GV3000 drives. The manual will help with both identifying 2AX3000 and understand the network connection on GV3000 drives.

Repair Services For 2AX3000

Type Lead Time Price Action
Repair Service 1-2 weeks $1159

Our highly skilled technicians can repair your 2AX3000. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

2AX3000 Manuals, White Papers, Data Sheets, and Troubleshooting
