The 20V2260 drive is a 20HP, 60Hz, 3-phase drive from Reliance Electric's GV3000 series that has a NEMA 12 enclosure, built-in keypad, and a input voltage range of 200-230 VAC.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 20V2260 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 20V2260
  • SKU: 20V2260RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

20V2260 Technical Specifications

Manufacturer Reliance Electric
Series GV3000
Part Number 20V2260
HP 20 HP
Input Voltage 200-230 VAC
Enclosure NEMA 12
Keypad/Display Built-In Keypad
Phase 3 Phase
Hz 60Hz
Instruction Manual D2-3388

Product Description

The 20V2260 device is an inverter AC drive that was created by Reliance Electric. The 20V2260 inverter AC drive can usually be found within the stock at AX Control, which you can check at any point in time by using our website. If you prefer, you can also check on this product’s availability by giving us a call during our weekday office hours.The 20V2260 inverter AC drive is designed to provide both general purpose and vector regulation for a wide array of applications. With vector regulation, the drive will be able to provide high dynamic response, control the motor speed in both directions with precision, and maintain full rated motor torque to zero speed. With general purpose regulation, the drive will be used for certain applications in motors that use adjustable speed control.

While extremely convenient and accessible, the dual-regulation system inherent to the 20V2260 drive may lead to significant faults in the function of the drive. One such fault that experienced often by owners of this GV3000 series drive is the "SRL" code fault, which represents a communication loss between the drive's regulator, PC, and OIM. This fault tends to be caused by a crucial error in Serial port communication cable, PC or OIM communication port setup, and can be rectified with a number of diligent checks and fixes to the aforementioned communication port and cable setups. For a more detailed description on this fault and other supplemental programming information for the GV3000 series of Reliance Electric drive, please reference Software Start-Up and Reference Manual D2-3359-6.

The 20V2260 inverter AC drive features several unique and crucial specifications, including but not limited to:

  • An input voltage range of between 200 and 230 VAC.
  • An input kVA rated at 29.8.
  • A maximum input amps of 75.0 and a maximum output Amps of 69.6.
  • A power loss at full load of 600 watts
  • An input AC fuse rating is 125 A
  • and finally a horsepower rating of 20 HP

The 20V2260 inverter AC drive uses a NEMA 12 enclosure, which is the type of enclosure that is meant to be used in indoor environments that need a drip-tight and dust-tight enclosure. The 20V2260 inverter AC drive is equipped with its own display and keypad. The keypad has numerous buttons that can be used for entering values into and navigating throughout the display. There are also numerous status LEDs located on the drive’s faceplate.

Frequently Asked Questions about 20V2260

What are the maximum input amps on 20V2260?
20V2260 has 75 maximum input amps.
What does the enclosure on 20V2260 indicate?
The NEMA 12 enclosure on 20V2260 indicates that 20V2260 is meant for indoor environments and 20V2260 requires a dust-tight/drip-tight enclosure.
What is the operating temperature for a Reliance GV3000 20V2260?
The operating temperature for 20V2260 should be between 0 and 40 degrees Celsius. The storage temperature for 20V2260 can be between -40 and 65 degrees Celsius.
How big is 20V2260?
20V2260 is 11.34 by 18.23 inches in dimension. 20V2260 weights 15.9kg.
Where can I find the manual for 20V2260?
We can provide you with the manual for 20V2260. The manual for 20V2260 is Reliance Manual D2-3388. The manual is for 20V2260 and other drives in between 1 and 20 HP, with 230 VAC. The manual is version 6.04 for 20V2260.
Does AX Control offer a repair service for the 20V2260?
AX Control repairs all GV3000 NEMA Style, Bookshelf, and Power Module Style drives. We have repaired the 20V2260 model on numerous occasions and can troubleshoot almost any diagnosis. Please contact us for a firm repair quotation.

Reviews For 20V2260

Internal Review
(5.0)

An eye-catching indoor model formerly manufactured for Reliance Electric's range of GV300 series products, this 20V2260-model drive offers a unique combination of 20HP and an input voltage rating of 200-230 VAC, all supported by drive's updated 6.0 regulator version. Available for repair here at AXcontrol, with a standard lead time of one to two weeks. - AX Control Lead Technician

Repair Services For 20V2260

Type Lead Time Price Action
Repair Service 1-2 weeks $1314

Our highly skilled technicians can repair your 20V2260. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
