The 1V4460 drive is part of the GV3000 series, which offers regulation for a large range of applications that require modifiable speed control of motors.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 1V4460 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 1V4460
  • SKU: 1V4460RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

1V4460 Technical Specifications

Manufacturer Reliance Electric
Series GV3000
Part Number 1V4460
HP 1 HP
Input Voltage 380-460 VAC
Enclosure NEMA 4X/12
Keypad/Display Built-In Keypad
Hz 50/60Hz
Instruction Manual D2-3359 & D2-3360

About the 1V4460

Reliance Electric’s 1V4460 is a 1HP and 2.0KVA pulse-width modulated (PWM) drive. The drive is part of the GV3000 series, which offers vector and regulation for a large range of applications that require modifiable speed control of motors. The drive uses vector regulation to maintain motor torque to zero speed, precisely control motor speed in either direction, and provide high dynamic response. It accepts 2.5 input amps and provides 2.1 output amps at 2 kHz, 4 kHz, and 8 kHz. When the drive is at full load, it experiences a power loss of sixty watts. The drive is also equipped for harsh operating environments and can survive ambient humidity up to 95% non-condensing. The alternate part numbers are 896.00.70 and GV3000U-AC002-AF-DBT.

The drive is equipped with a liquid-crystal display and a keypad, which allows users to locally adjust the parameters of the drive itself. Furthermore, there are LED indicators that keep users informed on the status of the device. The faceplate’s liquid-crystal display and LED indicators can give precise alarm codes which can be looked up in the software manual of the 1V4460, reducing the time required for troubleshooting. The keypad has a mounting bracket that connects the regulator PCB to the device.

This drive is protected by a 4X/12 NEMA type enclosure. This enclosure is not vented and comes with base and keypad gaskets. It is not meant for outdoor usage and comes dust and drip-tight. This enclosure meets both NEMA 4X and 12 ratings. With the enclosure, this drive weighs 6.3 kg and is 222.3 mm wide, 280.7 mm tall, and 200 mm thick. On the drive faceplate is a keypad. This keypad has several important functions including operating and programming the drive. The display on the keypad has a 7-segment, 4-character LED. This LED is in charge of indicating drive parameters and error codes.

Frequently Asked Questions about 1V4460

What is the input KVA on 1V4460?
1V4460 has a 2.0 KVA input.
What does the NEMA 4X/12 enclosure rating on 1V4460 mean?
The NEMA 4X/12 enclosure rating on 1V4460 encompasses both the NEMA 4X and NEMA 12 enclosure ratings. This enclosure means 1V4460 is not vented, 1V4460 is supplied with base and keypad gaskets, and 1V4460 is intended for use in indoor environments with a water-tight/dust-tight enclosure.
How do you know if the DC voltage is too high on a reliance 1V4460?
When the DC voltage is too high on 1V4460, fault code error OCb will appear on 1V4460's keypad. This fault code indicates the overcurrent at DC braking fault on 1V4460. To correct this fault on 1V4460, check parameters H.006 and H.007 on 1V4460. These parameters on 1V4460 are the DC braking start frequency and DC braking current parameters, respectively. Both parameters are tunable parameters.
Which manuals apply to 1V4460?
The manuals that apply to 1V4460 are manuals D2-3359 and D2-3360. These manuals for 1V4460 are the software and hardware manuals for GV3000 NEMA style drives and the manuals identify 1V4460 specifically. We're happy to send you copies of these manuals for 1V4460.

Reviews For 1V4460

Internal Review
(5.0)

This drive is pulse-width modulated, which means that the drive is capable of controlling average power delivered from an electrical signal. Pulse-width modulation is especially effective for motors, as they are less easily affected by the discrete switching of PWM. This feature makes the drive a highly effective unit for motor control and management. - AX Control Tech

Repair Services For 1V4460

Type Lead Time Price Action
Repair Service 1-2 weeks $1652

Our highly skilled technicians can repair your 1V4460. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
