Reliance Electric GV-3000 GV3000/SE 1 HP AC Drive.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

2 Year Warranty: Learn More

Sell Surplus: Have a 1V4151 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

1V4151

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 3.40 (5)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 3.40 (5)
  • Click a star to rate this product
Reliance Electric GV-3000 GV3000/SE 1 HP AC Drive.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

2 Year Warranty: Learn More

Sell Surplus: Have a 1V4151 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

1V4151 Technical Specifications

Enclosure Type 1/IP20
HP 1 HP
Hz 50/60Hz
Input Voltage 380-460 VAC
Instruction Manual D2-3359 & D2-3360
Keypad/Display Built-In Keypad
kW 0.75kW
Manufacturer Reliance Electric
Part Number 1V4151
Phase 3 Phase
Series GV3000

Product Description

The 1V4151 is a PWM GV3000 AC Drive that is 380-460 VAC and 1HP. It was originally made by Reliance Electric by was possibly also sold through ABB or Baldor Reliance.

The 1V4151 is digital 3-Phase, 50/60 Hz, and .75 kilowatts. It has a 30 kA short circuit rating and has a 2.5 amp input/2.1 amp output. It is rated at 2KVA with a 60w power loss. This drive can be rated for volt/hertz regulation or for vector regulation. A fuse that is rated 6 amps should be used with this drive.

The 1V4151 is in a NEMA 1 chassis. This chassis has air vents that help to promote airflow to its internal devices. It has a small flap that allows the user to access an RS-232 connection providing a way to connect a PC directly to the drive. It is important to make sure this drive has a very secure panel mounting. It should be installed onto a flat surface using the 4 factory-drilled holes on the back panel of the drive. M6 washers and bolts should be used to secure the drive into place. This installation hardware is sold separately from this drive and should be supplied by the user.

When replacing or installing new internal PCBs or modules to the 1V4151, it is vital to use an anti-static wrist band to prevent any type of static to buildup and possibly short out the internal circuitry. Please read the instruction manual for this drive before attempting to install or alter it.

Frequently Asked Questions about 1V4151

How should I plan before installing my 1V4151?
Before installing your 1V4151, you should read chapter 3 in the hardware reference, installation, and troubleshooting manual for 1V4151 - Manual D2-3360. Chapter 3 in the manual is specifically the "Planning Before Installation" chapter. This chapter in the manual will give you general requirements for 1V4151's installation site, wiring requirements for 1V4151, and much more.
How many input and output amps does 1V4151 have?
1V4151 has 2.5 input amps and 1V4151 has 2.1 output amps.
What tables will I find in the software manual for 1V4151?
In the software manual for 1V4151, Manual D2-3359, you will find tables in chapters 3, 4, and 5 of the manual. Chapter 3 in the manual has tables for: display range examples on 1V4151, drive status LEDS, and monitor mode LEDs. Chapter 4 in the manual has 7 tables, all dealing with programming 1V4151. Chapter 5 in the manual has tables for: list of alarm codes on 1V4151, list of fault codes on 1V4151, and fatal fault codes that can be reset on 1V4151. For a copy of the software manual for 1V4151 so that you can view these tables, request Manual D2-3359.
How do I choose the source of analog output on 1V4151?
To choose the source of the analog output signal on 1V4151, adjust parameter P.012, the Terminal Strip Analog Output Source parameter for 1V4151. This parameter is default set to 0, which is bipolar speed on 1V4151, but the parameter can be set to: 1 (bipolar torque), 2 (unipolar speed), or 3 (unipolar current at V/Hz or unipolar torque at vector).
