1V2450

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (6)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (6)
  • Click a star to rate this product
The Reliance Electric 1V2450 GV3000 drive is a versatile 1HP, 0.75kW AC drive that features a NEMA 4X/12-type enclosure, an input voltage of 200-230 VAC, and a Hz rating of 50 Hz.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 1V2450 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 1V2450
  • SKU: 1V2450RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

1V2450 Technical Specifications

Manufacturer Reliance Electric
Series GV3000
Part Number 1V2450
HP 1 HP
Input Voltage 200-230 VAC
Enclosure NEMA 4X/12
Keypad/Display Built-In Keypad
kW 0.75kW
Hz 50Hz
Instruction Manual D2-3362 & D2-3363

About the 1V2450

The 1V2450 drive is a 1HP AC drive from Reliance Electric's GV3000 series of drives. A cabinet-based drive, the 1V2450 model drive flaunts a NEMA 4x/12-type enclosure and a relatively muted input voltage rating of 200-230 VAC, for less high-powered automation needs. Similarly to MANY of the GV3000 series from Reliance, this drive has a Hz rating of 50Hz and produces a kilo wattage score of 0.75kW. A PWM or pulse-width-modulated drive, the 1V2450 offers dual regulation types in both vector and general regulation. The 1V2450 drive is a standard-sized GV3000 series drive at 16x16x16, and the weight of the drive sits at a solid ten pounds.

The versatility of the 1V2450 drive is only matched by its' solid voltage protection and insulation. This particular drive offers crucial features such as overload protection and short-circuit detection, decreasing the likelihood of faults such as:

  • the overcurrent at DC braking fault (fault code OCb),
  •  motor overload fault (fault code OL),
  • the drive power electronic overload fault (PUo),
  • and many more!

While the advanced surge protection and electrical work done on the 1V2450 GV3000 drive helps to avoid several relevant faults, other faults that may possibly inconvenience the 1V2450 drive owner are more than worth mentioning. A primary fault that one might manage to encounter with this GV3000-series drive is the overfrequency fault, represented on the drive's built-in keypad display as OF. This fault is oftentimes caused by the drive exceeding the maximum allowable output frequency, causing an excessive regenerating energy. In this fault's case, the drive's stability or slip compensation circuit may add frequency reference. If the drive's H.016 is ON, the searching current is too high, and the motor is too small. Corrective action for the OF fault would be to check the vector parameters of PPR, motor poles, and base frequency. If the issue is not found within the vector parameters, then checks on the V/Hz parameters of maximum speed, overfrequency, and slip compensation may be required. If the fault has not been identified within these stated parameters, then check the DC voltage, check the P.005 setting, increase 1V2450's deceleration time, and check the motor size relative to the power module. For more information on fault codes and AC drive maintenance for this model, please make reference to instruction manuals D2-3362 and D2-3363.

Frequently Asked Questions about 1V2450

What is the 1v2450?

The 1v2450 is a powerful 1 horsepower AC drive from Reliance Electric. Part of the GV3000 series, the 1v2450 functions as a PWM (pulse-width-modulated) drive, harnessing the art of precision control to deliver both vector and general-purpose regulation, making it a versatile solution intended for a wide array of applications.
Can AX Control repair my 1V2450?
Yes, we GV3000 drives are one of the primary products we repair. We'd love to repair your 1V2450. For a repair quote and estimated repair time on your 1V2450, speak to a sales representative for a sales quote on 1V2450.
How many power loss watts does 1V2450 have?
1V2450 has 60 power loss watts when 1V2450 is at full load.
What does the NEMA 4X/12 enclosure rating mean on 1V2450?
The NEMA 4X/12 enclosure rating on 1V2450 indicates 1V2450 is not vented. It also indicates 1V2450 is supplied with base and keypad gaskets and 1V2450 is intended for use in indoor environments that require a water-tight/dust-tight enclsoure. 1V2450 encompasses both NEMA 4X and NEMA 12 ratings with the NEMA 4X/12 enclosure.
What are the two manuals for 1V2450?
The manuals for 1V2450 are Manual D2-3362 and Manual D2-3363. Manual D2-3362 is the GV3000 1-20 HP, 230 VAC hardware manual for 1V2450. Manual D2-3363 is the GV3000 230 VAC General Purpose and Vector Duty Drive Manual for 1V2450. Each manual can be found on our website or we can send you a link to either manual with 1V2450.

Reviews For 1V2450

Internal Review
(5.0)

The 1V2450 GV3000 drive from Reliance Electric is a tantalizing option for your lower-horsepower AC automation needs. Featuring the built-in keypad typical of the celebrated GV3000 series of drives, this AC drive stands alone as a premier option for those seeking capable and extensive overload and short-circuit protections, or just a generally durable drive. Additional features of the GV3000 series' 1V2450 include the versatility of the drive's regulation, as it can competently handle both vector and general regulation. - AX Control Lead Technician.

Repair Services For 1V2450

Type Lead Time Price Action
Repair Service 1-2 weeks $1299

Our highly skilled technicians can repair your 1V2450. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
