Reliance Electric GV-3000 GV3000/SE 1HP Hz AC Drive.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 1V2150 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 1V2150
  • SKU: 1V2150RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

1V2150 Technical Specifications

Manufacturer Reliance Electric
Series GV3000
Part Number 1V2150
HP 1 HP
Input Voltage 200-230 VAC
Enclosure NEMA 1
Keypad/Display Built-In Keypad
Phase 3 Phase
Hz 60Hz
Instruction Manual D2-3362 & D2-3363

About the 1V2150

The 1V2150 is a GV3000 AC Drive that was 1HP and 200-230 VAC. It was initially created through Reliance Electric, but it could have also been sold by ABB or Baldor Reliance contingent on its production years. This is version 5.0 of this drive and is no longer being supported by Reliance because newer versions of this drive have been released. AX Control does try to keep it in stock.

The 1V2150 is 50/60Hz and 2.4 KVA. It has an input amperage of 6.1A and an output amperage of 5.1 A. The drive maintains a power wattage loss of 60W. This drive has the capacity to use both vector or V/Hz regulation. When using V/Hz, the drive can have a 110% continuous output current. When the vector regulation is in use a 150% overload can be achieved for one minute.

The 1V2150 is in a standard NEMA 1 style enclosure. It is vented and had a door that gives the user access to an RS-232 port without needing to remove the cover off of the enclosure. It is only meant for indoor applications. This enclosure is protecting the internal components that make up the drive. These components include two fan assemblies (one is internal), a membrane switch (keypad with a bracket), a GVPB board, a regulator, and a PISC board.  The regulator board can be attached to the keypad by using the mounting bracket that is attached to the keypad. The regulator is slid into the bracket directly behind the keypad so that its display is visible on the keypad.

Frequently Asked Questions about 1V2150

How much input KVA does 1V2150 have?
1V2150 has 2.4 KVA input.
What are the maximum input and output amps on a reliance 1V2150?
1V2150 has 6.1 maximum input amps. 1V2150 has 5.1 maximum output amps whether 1V2150 is at V/Hz or vector regulation.
What are the manuals for 1V2150?
The manuals for 1V2150 are Manual D2-3362 and Manual D2-3363. Manual D2-3362 is the GV3000 hardware reference, installation, and troubleshooting manual for 1-20, 230 VAC drives, including 1V2150. Manual D2-3363 is the GV3000 230V AC General Purpose and Vector Duty Drive Manual for 1V2150. Both manuals are important to 1V2150 and each manual will help you understand 1V2150 in various ways. For a copy of either manual, request the manuals for 1V2150 from us.

Repair Services For 1V2150

Type Lead Time Price Action
Repair Service 1-2 weeks $1252

Our highly skilled technicians can repair your 1V2150. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
