150ER4060

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.4 (5)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.4 (5)
  • Click a star to rate this product
The 150ER4060 model is a Bookshelf Drive produced by Red Lion without a CE filter. The input amperage on this device is 20, and a power loss of 250 watts. The enclosure rating for this device is IP20, NEMA 12, or NEMA 4x.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 150ER4060 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 150ER4060
  • SKU: 150ER4060RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

150ER4060 Technical Specifications

Manufacturer Reliance Electric
Air Pollution Pollution Degree 2, IEC 664
Transportation Temperature Range -25 to 70°C
Input Voltage 380-460 VAC
Enclosure IP20
Output Amps by Mode on 2 kHz in Vector 11.0
Phase 3 Phase
Hz 50/60Hz
Instruction Manual D2-3426 & D2-3427

Product Description

Before installing the 150ER4060 Bookshelf Drive it is vital to properly plan the installation to ensure that the environment that the drive is going to be mounted and installed in. Please make sure that no other devices are to be mounted behind the drive as doing so can cause issues. The area behind the drive needs to be kept clear of any extra power wiring and controls. Some of the conditions that must be taken into consideration when installing the drive are that the drive remains distant from any coolants, oil, or additional airborne pollutants, the drive will be installed in an area that is typically cool, dry, and clean; and that there is enough space for airflow.

There is a chapter in the D2-347-3 Manual in regards to installing the output power wirings. Output contactors are one of the power wirings that can be installed on the 150ER4060 drive; these contactors will provide an effective means of disconnecting the motor from the drive. Please note that the output contactors are completely optional output power wirings to the GV3000 drives.

One important feature regarding the 150ER4060 drive is that the model can be programmed to provide two different types of operational stops, one of which is the coast-to-rest stop. The coast-to-rest operational stop can turn off the transistor power device drivers when needed. The other operational stop is ramp-to-rest which will fire the transistor power device drives until the attached motor comes to a stop and will proceed to turn off the associated power devices.

Frequently Asked Questions about 150ER4060

How many input and output amps are there on 150ER4060?
150ER4060 has 20 input amps. 150ER4060 has 15 output amps.
Which manuals apply to 150ER4060?
There are two main manuals that apply to 150ER4060. The manuals are manuals D2-3426 and D-23427 and they're the software and hardware manuals for 150ER4060. The manuals are Reliance manuals and we can provide you with these manuals for 150ER4060.
What is the short circuit rating on 150ER4060?
150ER4060 has a short circuit sym RMS rating of 10kA.
What is the size of 150ER4060?
150ER4060 is 3.74 by 14.88 by 7.87 inches in dimension. 150ER4060 weighs 12lbs.

Reviews For 150ER4060

Internal Review
(5.0)

As the 150ER4060 drive can be used in both V/Hz and Vector Regulations there are several different output amps by mode at the carrier frequency which makes this an excellent model as the user can choose the frequency of output amperage. - AX Control Technician
