Product Description
The 2GU42007 is a Reliance Electric designed 7.5HP 3-Phase GP2000 AC V*S Drive. There is a possibility that it was also produced through Baldor Reliance and ABB depending on its manufacturing dates.
The 2GU42007 is a 460 VAC 10.7 KVA drive that has a maximum input amperage of 13.4 and a max output amperage of 11.1. It has a line frequency of 50/60 Hz and a max sine wave of 10.1 amps. It has a 0-10% input voltage torque boost. It has an acceleration and deceleration adjustment of 0.1 to 360 seconds. It has a linearity of +/-1%. It has the capacity to adjust its current limit by 50-150%. It has a 200% load overcurrent IET. It has a 0.96 displacement factor. It has a line voltage variation of +/- 10%. This drive has the capability to run more than one motor. When that happens, it is vital for each motor to have its own overload protection device. It is recommended that you use a 17.5A input fuse but the maximum you can use is a 20A input fuse.
The 2GU42007 is covered by a NEMA 12 enclosure. This enclosure and drive weighs 13 kg. It is 408 mm tall, 256 mm wide, and 202 mm deep. There are many important drive components sheltered by this enclosure. There are DC bus capacitors, input sensory assembly, precharge resistor, noise filter, precharge relay, ground terminals, cooling fan, control transformer, voltage detect resistor, DC bus fuse, transistor module, bus clamp assembly, hall effect current sensor, ground terminals, leakage current sensor assembly, discharge resistor, current transformers, and a diode cube. There is also a regulator that is attached to a keypad.
