14C101U Reliance Electric Rockwell FlexPak Plus .75HP 1PH Drive.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 14C101U to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 14C101U
  • SKU: RE-1867
  • Manufacturer: Reliance Electric
  • Series: FlexPak Plus

14C101U Technical Specifications

Manufacturer Reliance Electric
Series FlexPak Plus
Part Number 14C101U
HP 0.75 HP
Input Voltage 115 VAC
Hz 50/60Hz
Phase 1 Phase
Weight 4.04 lb

About the 14C101U

  • The 14C101U is a full-wave converter manufactured by Reliance Electric, officially known as a Reliance Rockwell Flexpak Plus .75HP-1PH Drive.
  • It features an analog major loop and an analog current minor loop for armature voltage and speed regulation via tachometer feedback.
  • A nameplate on the front cover displays the model and serial number.
  • Important information like AC power input and DC power output data are also marked on the nameplate.

Variants: Basic vs. Complete Chassis Controller
  • The 14C101U comes in two variants:
    • Basic Chassis Controller:
      • No auxiliary panel.
      • Lacks power converter, regulator, field supply.
      • No AC power fuses or armature loop contactor.
      • Typically supplied by third-party vendors without the auxiliary panel.
    • Complete Chassis Controller:
      • Always includes the auxiliary panel.
      • Contains the power converter, regulator, and field supply.
      • Includes AC fuses and armature loop contactor.
      • Provided as a complete package by official sellers.

Modification Kits
  • Reliance offers a vast array of modification kits to enhance the controller's capabilities.
  • These kits are mostly plug-and-play, connecting to specific circuits on the control panel.
  • Kit numbers and details are provided in the user manual for the controller.

Reviews For 14C101U

Internal Review
(5.0)

The Reliance Electric 14C101U Flexpak Plus .75HP-1PH Drive is a versatile full-wave converter offering precise armature voltage and speed regulation through its analog major and minor current loops, utilizing tachometer feedback. A defining characteristic of the 14C101U is its availability in two distinct variants: a basic chassis controller and a more equipped complete chassis controller. The basic version, often supplied by third parties, lacks an auxiliary panel and several core components like power converters, regulators, field supplies, AC power fuses, and armature loop contactors. In contrast, the complete chassis controller, provided by official sellers, includes all these essential components within a single package. – AX Control Technician

Repair Services For 14C101U

Type Lead Time Price Action
Repair Service 1-2 weeks $1602

Our highly skilled technicians can repair your 14C101U. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
