Reliance Electric's 912FK0400 Dynamic Braking Kit provides the hardware required to initiate dynamic braking on stop.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 912FK0400 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 912FK0400
  • SKU: 912FK0400RE
  • Manufacturer: Reliance Electric
  • Series: FlexPak 3000

912FK0400 Technical Specifications

Manufacturer Reliance Electric
Series FlexPak 3000
Part Number 912FK0400
User Manual D2-3404-2
Part Type Dynamic Braking Kit

About the 912FK0400

Reliance Electric’s 912FK0400 Dynamic Braking Kit provides the hardware required to initiate dynamic braking on stop. The unit includes braking grids and enhances the braking performance and overall efficiency of the motor control system. Due to the fact that uncontrolled motor inertia can lead to lengthy stopping times and system damage, the decelerating functions of the Dynamic Braking Kit are highly effective in reducing stopping time and increasing the efficiency and safety of the FlexPak 3000 DC Drive. The kit also dissipates excess kinetic energy generated during deceleration, allowing for faster and more controlled stops.

The 912FK0400 Dynamic Braking Kit incorporates vital safety features that ensure the safety of both personnel and equipment during routine operation. The braking module includes fault detection and protection mechanisms to prevent overheating or excessive current flow. The kit is designed to be compact and can be installed on the top of the electrical cabinet in a solid-plate enclosure or an expanded sheet-metal enclosure.

The 912FK0400 Dynamic Braking Kit also includes a braking module that works in conjunction with the dynamic braking resistor. This module monitors the motor's speed and voltage, engaging the dynamic braking resistor when deceleration is detected.

Frequently Asked Questions about 912FK0400

What is the purpose of the 912FK0400?
The 912FK0400 is a dynamic braking kit that is used to slow down a drive's motor and load when the drive stops running correctly. When the load is heavy, the drive is more likley to have an issue and the 912FK0400 is recomended.
What type of drive is compatible with the 912FK0400?
The 912FK0400 is compatible with Reliance Electric FLexPak 3000 drives that have an HP of 40. The 912FK0400 is compatible with drives that have both a VAC of 230 and 460.
Is the 912FK0400's contactor suppose to remain open?
The 912FK0400's contactor remains open when the drive is running smoothly and when the dynamic braking resistor is disconnected.
Can AX Control repair my 912FK0400?
Yes, please send us your 912FK0400 for any repairs needed. Our AX Control technicians are able to complete board level repairs on a variety of devices.

Reviews For 912FK0400

Internal Review
(5.0)

Both the 912FK0400 Dynamic Breaking Kit and the FlexPak 3000 are hardened against environmental conditions in perform effectively in a range of operating environments; this reduces system downtime and ensures maximal system life. - AX Control Tech
