Reliance Electric 40FR4032 FlexPak 3000 40HP Regenerative Drive

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 40FR4032 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 40FR4032
  • SKU: 40FR4032RE
  • Manufacturer: Reliance Electric
  • Series: FlexPak 3000

40FR4032 Technical Specifications

Manufacturer Reliance Electric
Series FlexPak 3000
Part Number 40FR4032
HP 40 HP
Input Voltage 460 VAC
Hz 50/60 Hz

About the 40FR4032

The 40FR4032 is a 40 HP 460 VAC FlexPak 3000 Drive made by Reliance Electric. It may have also been sold by ABB or Baldor Reliance.

The 40FR4032 is classified as a regenerative drive. It has a 63 amp full load rated RMS AC line current and a DC line current of 73 amps. It has a rated field current of 15 amps.  It has a line voltage variation of +/-10%. It has a 48/62 Hz AC line frequency. This drive weighs 26.4 kg and is 500 mm tall, 270 mm wide, and 281.2 mm thick.

Some of the basic features of the 40FR4032 include an AC line disconnect that is located in the top right side of the drive, AC line fuses that are located to the left of the disconnect, a fused blower motor starter that is in the top left corner, an operator interface module (OIM) located in the center of the drive, an internal terminal strip that can be used for I/O, a surface mounted regulator board, and an enhanced field supply. It also boasts a compact chassis design. The OIM or keypad/display is vital to the user being able to start the drive, monitor its status, and control its functions. It has an easy to read LCD screen.

The 40FR4032 should be only kept in an area that is totally free from liquids, dust, extreme temperatures, corrosive and combustible materials, caustic vapors, shock or vibration, and electrical or electromagnetic noise interference. This chassis should be mounted vertically onto a metallic flat surface like a panel.

Frequently Asked Questions about 40FR4032

Can the 40FR4032 be converted to a 230 VAC drive?
Yes, the FlexPak 3000 series has drive modification kits that can convert the 40FR4032 to a 230 VAC drive. A 460 drive can be converted to 230 VAC but 230 VAC drives can not be converted to a 460 VAC drive.
Where can I find the FlexPak 3000 series manual?
The FlexPak 3000 series manual has detailed information on the 40FR4032 and other drive models in the series. Please contact AX Control if you would like us to send you a copy of the manual.
What is the function of the 40FR4032's Quick Start feature?
The 40FR4032 comes equipped with a Quick Start feature that provides for a quick and simple drive set up. The Quick Start menu is where the user can go to adjust parameters and find diagnostic information.
What do the two LED's located on the regular board indicate about the 40FR4032?
The 40FR4032's regulator board has toe LED lights that indicate the status of the drive. If the LED lights are off, there is no power to the drive, the LED lights have failed, or the regulator board needs replacing.
