Reliance Electric 9101-1133 120/240 Brushless Servo DM-30 30 Amp Drive

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

2 Year Warranty: Learn More

Sell Surplus: Have a 9101-1133 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9101-1133

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
Reliance Electric 9101-1133 120/240 Brushless Servo DM-30 30 Amp Drive

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

2 Year Warranty: Learn More

Sell Surplus: Have a 9101-1133 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

9101-1133 Technical Specifications

Hz 50/60 Hz
Input Voltage 100/240 VAC
Manufacturer Reliance Electric
Phase 1 Phase
Product Number 9101-1133
Rev J
Series BRU-200

Product Description

The 9101-1133 is a DM-30 model in the BRU-200 Series of servo drives. There is a good chance that it was offered under the ABB or Baldor Reliance labels depending on when it was sold.

The 9101-1133 is a brushless single-phase servo drive. It is in charge of ensuring that the motor has power and is controlled. It has a 120/240 VAC input voltage and a frequency of 50/60 Hz. It has the ability to maintain a continuous 15 amps and a peak of 30 amps. It can keep a 4.5-kilowatt peak shunt and a continuous shunt of 50 watts. It typically weighs around 6.8 kilograms. It is recommended by the original manufacturers that this drive should be used in combination with either an F-series or S-series Electro-Craft motor. The motors that are suggested are the F-4075, F-4050, S-4075, and S-4050.

On the 9101-1133 next to the faceplate, the user can see some of the internal circuitry because the chassis is open. The faceplate has many different external components that include a terminal strip and a series of LED lights. The terminal strip has the ability to connect to I/O and directly to the motor. This strip is located on the left side of the faceplate. There is another set of six connectors on the right side that is labeled P1, P2, P3, P4, P5, and P6. They are also labeled with what type of connection they are. On the bottom of the drive is an external fan assembly that helps to keep the air moving through the internal circuitry.

Frequently Asked Questions about 9101-1133

What is the function of the 9101-1133?
The 9101-1133 is a high performanDM-30 Drive within the BRU-200 Series. The 9101-1133 provides power and a controller for any Reliance Electric motor.
Where can I find the manual for the 9101-1133?
There is not a specific manual for the 9101-1133 but the BRU-200 series manual has detailed informantion on the drive. You can contact AX Control for the manual or search the manual number 0013-1028-001.
How are the 9101-1133 and the 9101-1303 similar?
Both the 9101-1133 and the 9101-1303 are DM-30 drives but the 9101-1133 has a J rev while the 9101-1303 has a A rev.
What type of enclosure does the 9101-1133 have?
The 9101-1133 is enclosed within a NEMA 12K enclosure.
