DC2-62U

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
Rockwell Flat Plate Motor Controller 62U with Added Speed Control

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a DC2-62U to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DC2-62U
  • SKU: DC262URE
  • Manufacturer: Reliance Electric
  • Series: DC2 Drives

DC2-62U Technical Specifications

Manufacturer Reliance Electric
Series DC2
Part Number DC2-62U
HP 1.0/2.0 HP
Input Voltage 115/230 VAC
Phase 1 Phase
Hz 50/60Hz

About the DC2-62U

The Rockwell Flat Plate Motor Controller is a part of Reliance Electric's System of parts. This controller is a NEMA 12 enclosure. This means that the device works in a harsher environment.  The best ambient temperature for installation is between 0 to 40 degrees Celsius. The Rockwell Flat Plate Motor Controller comes with all the basics of a controller, but with great added features. This controller comes with a potentiometer that allows adjustment of the motor speed. There are many adjustable settings on this controller. The current limits, the minimum speed, and the maximum speed can change at the user's request. This product also has a secondary IGBT available. This device can be remotely controlled. Which means, from a distance, the user still has the ability to interact with the controller. This device also has a product control interface that integrates into the system.

The Rockwell Flat Plate Motor Controller has a variable horsepower of  1 or 2. The output current of the system varies depending on the voltage setting that the controller is currently on. At 115V, the controller has an output current of 90KVA. At 230, the, controller has an output current of 180KVA. The Controller has the 1 minute load capacity of 150% and has an efficiency rating of 97%.

The Rockwell Flat Plate Motor Controller has 1 input phase to do its work with. The system boasts a 1.5KVA transformer and an input voltage of 115V or 230V at 50/60Hz. The device also has a input rating of 6.2 at 115V, and an input rating of 3.1 a 230V. Speed control has been added to this model to add even more choice to the system.

Frequently Asked Questions about DC2-62U

What enclosure does DC2-62U have?
DC2-62U has a NEMA 12 enclosure rating. Water-tight conduit hubs are standard on a DC2-62U because of the NEMA 12 enclosure.
What type of controller features does a Reliance DC2-62U have?
According to the DC2 Drive Instruction Manual, DC2-62U has basic plus process control features. For a list of these features, ask for a link to the manual. The manual is an installing, operating, and maintaining manual for DC2 drives.
What type of control does DC2-62U have?
DC2-62U uses speed control. This means that there is an element in the DC2-62U that detects speed. The DC2-62U controls the speed of its' motor by increasing or decreasing applied voltage to the DC2-62U motor.
Where can I find the manual for the DC2-62U?
AX Control has the DC2 Series manual that includes specific information about the DC2-62U. You can contact us for the manual or search the manual number 02-3231-3.

Repair Services For DC2-62U

Type Lead Time Price Action
Repair Service 1-2 weeks $470

Our highly skilled technicians can repair your DC2-62U. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
