Reliance Electric Rockwell DC2-60U 1.0/2.0 HP 40/60 Hz Enclosed in a NEMA 12k Enclosure

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a DC2-60U to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DC2-60U
  • SKU: RE-18177
  • Manufacturer: Reliance Electric
  • Series: DC2 Drives

DC2-60U Technical Specifications

Manufacturer Reliance Electric
Series DC2
Product Number DC2-60U
HP 1.0/2.0
Input Voltage 115/230 VAC
Phase 1 Phase
Hz 50/60 Hz

About the DC2-60U

The DC2-60U is a DC2 Drive Controller that was manufactured by Reliance Electric. The DC2-60U can convert single phase AC line power into adjustable DC power for speed control of DC motors. These motors are rated 1/4 to 2 horsepower.

The DC2-60U is designed specifically for speed control, which gives this model extra features. Some of the features are:

  • Potentiometer motor speed adjustment
  • Adjustable current limit
  • Adjustable IR drop compensation
  • Independently adjustable rates

The DC2-60U also has jog functions, which include run and jog capabilities for local and remote requirements.

Frequently Asked Questions about DC2-60U

Does the DC2-60U have an adjustable current limit?
The DC2-60U is designed with an adjustable current limit.
Where can I find the manual for the DC2-60U?
There is not a specific manual for the DC2-60U but there is a DC2 series manual with information specific to the DC2-60U. You can find the manual using the manual number 02-3231-3.
What type of IGBT does the DC2-60U have?
The DC2-60U has a 701819-14AB IGBT that is located under the main circuit board.
Can AX Control repair my DC2-60U?
AX Control technicians can complete board level repairs to get your device fully functioning again.

Reviews For DC2-60U

Internal Review
(5.0)

The DC2-60U is made to work with Reliance Electric motor specifically. The DC2-60U has a NEMA 12 enclosure, which protects the model from oil and dust. One of the basic functions of the DC2-60U is its short circuit protection by incoming line fuse. This is an optional protection feature. - AX Control Lead Technician
