Open Chassis Rockwell Flat Plate Motor Controller 52U

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a DC2-52U to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DC2-52U
  • SKU: DC252URE
  • Manufacturer: Reliance Electric
  • Series: DC2 Drives

DC2-52U Technical Specifications

Manufacturer Reliance Electric
Series DC2
Part Number DC2-52U
HP 1.0/2.0 HP
Input Voltage 115/230 VAC
Phase 1 Phase
Hz 50/60 Hz

About the DC2-52U

The Rockwell Flat Plate Motor Controller is a part of Reliance Electric's System of parts. This controller is an open chassis enclosure. This means that the device works best in an indoor and clean environment. The best ambient temperature for installation is between 0 to 55 degrees Celsius. The Rockwell Flat Plate Motor Controller comes with all the basics of a controller, but with great added features. There are many adjustable settings on this controller. This controller comes with a potentiometer that allows adjustment of the motor speed. The current limits, the minimum speed, and the maximum speed can also change at the user's request. This product also has a secondary IGBT available. This device can be remotely controlled. Which means, from a distance, the user still has the ability to interact with the controller. This device also has a product control interface that integrates into the system.

The Rockwell Flat Plate Motor Controller has a variable horsepower of  1 or 2. The output current of the system varies depending on the voltage setting that the controller is currently on. At 115V, the controller has an output current of 90KVA. At 230, the, controller has an output current of 180KVA. The Controller has the 1 minute load capacity of 150% and has an efficiency rating of 97%.

The Rockwell Flat Plate Motor Controller has 1 input phase to do its work with. The system boasts a 1.5KVA transformer and an input voltage of 115V or 230V at 50/60Hz. The device also has a input rating of 6.2 at 115V, and an input rating of 3.1 a 230V.

Frequently Asked Questions about DC2-52U

What type of regulator is the DC2-52U equipped with?
The DC2-52U is equipped with a basic regulator with instrument interface.
Can AX Control troubleshoot my DC2-52U?
AX Control technicians are able to troubleshoot your DC2-52U if it is not functioning correctly. AX Control can find the issue and complete any repairs needed.
What type of enclosure does the DC2-52U have?
The DC2-52U is kept in an open chassis enclosure that is designed for cool and clean enviornments.
What controller features is the DC2-52U equipped with?
The DC2-52U is equipped with the basic controller features as well as a process control interface.

Repair Services For DC2-52U

Type Lead Time Price Action
Repair Service 1-2 weeks $449

Our highly skilled technicians can repair your DC2-52U. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
