Reliance Electric DC2-45U 1.0/2.0 HP 50/60 Hz Drive with a Open Chassis Enclosure

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

2 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a DC2-45U to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: DC2-45U
SKU: RE-18170

Manufacturer: Reliance Electric
Series: DC2 Drives

Description
Repairs
Warranty
Manuals

DC2-45U Technical Specifications

Manufacturer	Reliance Electric
Series	DC2
Part Number	DC2-45U
HP	1.0/2.0 HP
Input Voltage	115/230 VAC
Phase	1 Phase
Hz	50/60 Hz

About the DC2-45U

The DC2-45U is a DC2 Series Drive Controller that was manufactured by Reliance Electric. This controller is designed to convert single phase AC line power into DC power for speed control of DC motors. The DC2-45U is specifically designed for Reliance DC motors, which allows for a better, more compact controller/motor pair.

The DC2-45U has basic features of the DC2 Series and speed control features. Some of the basic features that the DC2-45U has are:

Provisions for remote start, remote stop and remote run/jog
Half wave field supply for shunt wound DC motors
Unidirectional operation with coast-to-rest stop

Some of the speed control features include:

Speed control by armature voltage regulation or motor mounted DC tachometer
Independently adjustable rates
Adjustable IR drop compensation

Frequently Asked Questions about DC2-45U

What type of main circuit board is the DC2-45U designed with?

The DC2-45U has the 0-57210-30 installed as the main circuit board. The 0-57210-30 sets on top of the flat plate and IGBT.

Where can I find the manual for the DC2-45U?

The DC2 series manual provides information on all devices within the series. You can contact AX Control for the manual or search the manual number 02-3231-3 online.

What speed control features does the DC2-45U have?

The DC2-45U has multiple speed control features including adjustable maximum and minimum speeds as well as an adjustable current unit.

Does AX Control provide a warranty on the DC2-45U?

AX Control will provide a two year warranty on the DC2-45U. If the device stops working we will send you a new device, grant you a full refund, or complete any repairs it needs.

What type of IGBT does the DC2-45U have?

The DC2-45 comes equipped with a 701819-14AB IGBT.

Repair Services For DC2-45U

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	$483

Our highly skilled technicians can repair your DC2-45U. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
