Automate Resistor Scaling Module

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 805427-1S to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 805427-1S
  • SKU: 8054271SRE
  • Manufacturer: Reliance Electric
  • Series: AutoMax PLC

805427-1S Technical Specifications

Manufacturer Reliance Electric
Series AutoMate PLC
Part Number 805427-1S
Product Type Resistor Scaling Module

About the 805427-1S

The 805427-1S unit is a resistor scaling module by Reliance Electric for the AutoMax PLC series. This particular product is no longer available from Reliance Electric, but AX Control still regularly stocks it for our customers. You can check to see if it is available by looking on our website.

The 805427-1S module is one part of the whole resistor scaling module. The other half of the resistor scaling module uses the model number 805401-2S. If you are in need of that part to go along with your 805427-1S module, then be sure to click on the link that is associated with it to be brought to its page on our website. From there, you will be able to learn some more about it, find out if it is available in our stock, and see the purchasing and shipping information for it.

The 805427-1S resistor scaling module consists of numerous components throughout its surface. There are three large transformers on the right side of the module. Underneath these three transformers, you will see numerous wires that connect to various other parts on the 805427-1S resistor scaling module. For instance, some of these wires connect to the many terminals on the left side of the board. These terminals are labeled as follows from top to bottom: “191,” “192,” “195,” “196,” “L1,” and “L2.” At the top of the module, there are numerous fuses with wires connected to them. At the bottom of the module, there is a large power supply with two wires connected to it.

The 805427-1S resistor scaling module weighs about 6.65 lbs. or 3.02 kg.

Frequently Asked Questions about 805427-1S

What is the maximum input on 805427-1S?
805427-1S has a maximum input of 800V RMS.
What is the input voltage on 805427-1S?
805427-1S has 480 VAC input.
What is the output connected to on 805427-1S?
The output connects to PMI on 805427-1S. There is an input connector on the bottom right side of 805427-1S and the output to PMI connector is directly above it on 805427-1S.
