16 Slot Reliance Automax Rack.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 803456-1R to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 803456-1R
  • SKU: 8034561RRE
  • Manufacturer: Reliance Electric
  • Series: AutoMax PLC

803456-1R Technical Specifications

Manufacturer Reliance Electric
Series AutoMax PLC
Part Number 803456-1R
Product Type 16-Slot Rack
Instruction Manual J2-3008

Product Description

The 803456-1R is a rack that was made by Reliance Electric. The 803456-1R rack is no longer in production, but AX Control still typically has it in stock. The availability of this product is listed on this page of our website. Be aware that this product was also manufactured using the product number 57c331 or a number with a similar variation.

The 803456-1R rack has a total of sixteen slots where it can fit AutoMax PLC modules. There is also a slot on the far left side for an AutoMax power module. Located in between the power module and the slots for the AutoMax modules, you will find a few integrated circuits. There are also some integrated circuits on the far right side of the rack. In between some of the slots for the AutoMax modules, you will be able to see some small resistors. The bottom left corner of the module’s front side is home to its ON/OFF switch, directly next to a small CAUTION label. The very bottom of the module is home to two large high-capacity cooling fans with a surge protector in between them. There are numerous wires coming from all three of these components. Also on the 803456-1R rack, you will find an AC line filter and a cable management tray. The way that this rack is designed makes it easy for panel-mounting procedures.

The 803456-1R rack is rated at 100/120 VAC, 8/7 A, and 50/60 Hz. The maximum source for this module is 50 kVA and the backplane has the model number 57516-1C.

Frequently Asked Questions about 803456-1R

What is the shipping weight of 803456-1R?
803456-1R has an estimated shipping weight of about 5lbs.
What slot position is the DCS DC Drive in on a Reliance 803456-1R?
On 803456-1R, a DCS DC Drive is located in slot positions 6-9 and 12-15 in 803456-1R.
Is there a fan on 803456-1R?
Yes there are two fans on 803456-1R.
Which manual identifies 803456-1R?
Manual J2-3008 is the manual that identifies 803456-1R. The manual is a Reliance manual for 803456-1R and the manual provides description of 803456-1R, a diagram of 803456-1R, and technical specifications of 803456-1R.
