Reliance Automax 2 Axis Servo Controller Module.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 57C422 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 57C422
  • SKU: 57C422RE
  • Manufacturer: Reliance Electric
  • Series: AutoMax PLC

57C422 Technical Specifications

Manufacturer Reliance Electric
Series AutoMax PLC
Part Number 57C422
Product Type 2-Axis Servo Module
Instruction Manual J-3642

Product Description

The 57C422 is a Servo Controller Module that was initially designed and mass-produced by Reliance Electric. There is a strong probability that this device was also produced and sold by Asea Brown Boveri and Baldor Reliance. It all depends on what the years were that this part was actually in production.

Reliance Electric created the 57C422 as a 2-Axis servo module to be used with an AutoMax Multibus system I/O. This system has the ability to maintain a direct bus interface to an AutoMax or DCS 5000 processor. So that the system can keep total control over its dual-axis, it must use a digital motion controller and maintain an 80186 (or equivalent) microprocessor. The current types do not matter because this system can be used to maintain the management of both AC and DC servo amplifiers and drive systems. This system also has an onboard watchdog system that is used to interlock a relay in the drive-enabled electrical system.

The 57C422 has a bank of 8 LEDs labeled X HOME, X+OTRAV, X-OTRAV, X FAULT, X F.REG, X G.REG, X ENABLE, and X SP. It also has a bank of 4 LEDs labeled STAT 3, STAT 2, STAT 1, and DRAG. It has a large green LED labeled OK. Under that is another bank of 8 LEDs labeled Y HOME, Y+OTRAV, Y-OTRAV, Y FAULT, Y F. REG, Y G.REG, Y ENABLE, and Y SP. Under the LEDs, this module has two RS-232 female connection ports that are labeled X and Y.

Frequently Asked Questions about 57C422

What electrical parts does 57C422 contain?
57C422 contains an 80186 microprocessor, local RAM, and EPROM for the axis software as far as 57C422's main electrial components. 57C422 also contains 4k x 15 dual port memory so 57C422 can transform data to and from 57C422 and the application software.
What do the axis' 57C422 contains?
Each axis on 57C422 contains digital inputs for the drive fault, home L/S, and positive and negative overtravel L/S. Each axis on 57C422 also contains a watchdog output that can be used by 57C422 to disable the drive if 57C422 falls.
Is there any rack that 57C422 cannot be used in?
57C422 cannot be used in a remote rack.
Where do I obtain the manual for 57C422?
We are happy to send you the manual for 57C422. The manual is Manual J-3642, which is the 2-Axis Servo Module Manual for 57C422. The manual addresses mechanics and electrics of 57C422, the manual goes through installation and programming 57C422, and the manual has a section on applying 57C422, and restrictions for 57C422.
  • 57C422A
  • 57C422B
  • 57C422C
