57C-420 Automate DCS 5000 5-24V 32 Channel DC Output Module.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 57C420 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 57C420
  • SKU: 57C420RE
  • Manufacturer: Reliance Electric
  • Series: AutoMax PLC

57C420 Technical Specifications

Manufacturer Reliance Electric
Series AutoMax PLC
Part Number 57C420
Product Type Output Module
Instruction Manual J-3720

Product Description

Reliance Electric designed the 57C420 to be a DC Output Module. Depending on the years it was in production, this component was also probably sold as a Baldor Reliance or Asea Brown Boveri product.

The 57C420 was created to be a component within an AutoMax system. This output module has 32 channels that produce 750 mAmps per channel. It is rated 5-24 VDCs. This component has a 5000-volt isolation that is between the logic commons and the outputs. It also has four outputs per each of these isolated commons. This unit is comprised of a circuit board with a faceplate that has been protectively encased in a hard enclosure. The 57C420 has a maximum operating voltage of 30 DCV. This module should only be operating in temperatures between 0 and 60 degrees Celsius.

The 57C420 has a bank of indicator LEDs. They are numerically labeled with the numbers 0 to 31. This system also has two RS-232 cables that are labeled CN1 and CN2. You can use 57C376 cables to connect to these ports. These cables are sold separately from this module. This module is comprised of a circuit board with a faceplate that has been protectively encased in a hard enclosure. This entire setup can be put in an AutoMax card storage rack. To put it on the rack, you need to slide it into the female card slots that are positioned on the backplane of the rack. After it is in place, you can secure it by attaching two screws to the braces on the module and rack.

Frequently Asked Questions about 57C420

How many outputs does 57C420 have?
57C420 has 32 outputs with a maximum current of 750 ma per output on 57C420.
What is the size of a Reliance 57C420?
57C420 is 11.75 by 1.25 inches and 57C420 is 7.375 inches in depth.
What is the manual for 57C420?
The manual for 57C420 is the 5-24V DC Output Module Manual, a manual only for 57C420. The manual is Manual J-3720 and we can provide the Reliance 57C420 manual to you.

Repair Services For 57C420

Type Lead Time Price Action
Repair Service 1-2 weeks $298

Our highly skilled technicians can repair your 57C420. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
