Reliance Electric Automax Automate Interface Module.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 57C417 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

57C417

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (6)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (6)
  • Click a star to rate this product
Reliance Electric Automax Automate Interface Module.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 57C417 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

57C417 Technical Specifications

Manufacturer Reliance Electric
Part Number 57C417
Product Type Interface Module
Series AutoMate PLC

Product Description

The 57C417 is a Reliance Electric designed Interface Module. This interface was very possibly produced and sold by Asea Brown Boveri or Baldor Reliance depending on what year it was being manufactured. This interface is no longer being supported by any of these original companies. AX Control does attempt to keep the 57C417 in stock. Please check our website for its availability status.

The 57C417 is an Interface that was specifically made to be a component of the AutoMax system. The 57C417 has a max 20-watt power degeneracy. Its main objective is to promote communication with an AutoMax system using a straightforward RS-232 connection. The AutoMate Communication Protocol is used to accomplish this. This module can be linked to lots of different AutoMate modules. It can also be attached to the R-NET network utilizing an R-Net Gateway Interface Head. It can be connected to a serial communication processor. Doing this will allow it to communicate with multiple AutoMate processor modules. You have the choice of not using the Serial Communication Processor and linking the 57C417 just a standard AutoMate processor.

This component cannot actually physically initiate an interface between devices. It must act as a slave device; responding only to commands from its operator. It can be placed in any slot on an AutoMax card rack that is not taken up by a processor or a Common Memory Module. It has a dual-port memory and can interface with as many as four other processors. It has a Fault Code LEDs that help alert the user to errors in the system. It also has a green LED light that is labeled OK.

Frequently Asked Questions about 57C417

What is 57C417's power requirement?
57C417 should have 2.5 power at +5V and 57C417 should have 0.053 at +12V.
What does 57C417 interface?
57C417 interfaces the AutoMax to the Reliance AutoMate programmable controller equipment.
What LED status indicators does 57C417 have?
57C417 has a 7-segment LED for faults in which the 57C417 displays status and error codes. 57C417 also has an "OK" LED that indicates 57C417 is functioning properly.
What kind of thumbwheel switch does 57C417 have?
57C417 has a "DROP NUMBER" thumbwheel switch. The thumbwheel switch on 57C417 is the drop or device number for the appropriate equipment or network.
