57C-413 Rockwell Automate 64K Common Memory Module.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 57C413 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 57C413
  • SKU: 57C413RE
  • Manufacturer: Reliance Electric
  • Series: AutoMax PLC

57C413 Technical Specifications

Manufacturer Reliance Electric
Series AutoMax PLC
Part Number 57C413
Product Type Common Memory Module
Instruction Manual J-3636

Product Description

The 57C413 is a Reliance Electric Common Memory Card. This module was sometimes also produced by Asea Brown Boveri or Baldor Reliance. This part is not being supported by any of these manufacturers anymore, but AX Control does try to keep this component in stock.

The 57C413 is a 64k word upgrade for an AutoMax System. It has a lithium battery-backed RAM that can be easily replaced. When the battery is installed into the system, the RAM has a 600 to 2000-day retention rate. When the battery is removed or is consumed it has a 130 to 400-minute retention rate. This module takes a 1.05A @5VDC backplane current load. This module has the ability to extend a single processor’s storage data.

The 57C413 is a very simple slim component. The only thing it has on its faceplate is a green LED that is labeled SYSTEM WATCHDOG. This module typically goes on the rack to the right of the power supply and goes into Slot 0 if you are using it with more than one processor. When you are configuring the rack with multiple processors, you must plug a processor into slot 1 or keep it open. If you are only using the memory card with a single processor, it can then go into any even slot that is not taken up by the power supply.  However, the slot to the right of it must remain empty when it is configured this way on the rack. You can easily slide the memory module into place into the female card slots on the backplane of the rack.

Frequently Asked Questions about 57C413

Which slot does 57C413 fit in?
57C413 not only fits in slot 0 of a DCS 5000/AutoMax rack but 57C413 is required in a rack that contains more than one processor module. 57C413 also fits in slot 0 of a single-processor rack.
What does the "BAT.OK" status LED on 57C413 indicate?
The "BAT.OK" LED on 57C413 indicates whether the on-board battery is providing adequate voltage to retain the contents of RAM or should be replaced.
Does AX Control have reconditioned 57C413 modules available?
Yes, we should have reconditioned 57C413 modules. To check the status of our inventory on 57C413, speak to a sales representative about purching a reconditioned 57C413. Our recondionted products are more affordable yet still work just as good!
Is manual J-3636 specific to 57C413?
Yes, manual J-3636 is the manual specific to 57C413. The manual is the Common Memory Module Manual and the manual is for 57C413 and model number 57C423 only.
  • 57C413-A
  • 57C413-B

Repair Services For 57C413

Type Lead Time Price Action
Repair Service 1-2 weeks $391

Our highly skilled technicians can repair your 57C413. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
