Automax Automate Processor Battery

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 57C385 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 57C385
  • SKU: 57C385RE
  • Manufacturer: Reliance Electric
  • Series: AutoMax PLC

57C385 Technical Specifications

Manufacturer Reliance Electric
Series AutoMax PLC
Part Number 57C385
Product Type Replacement Battery
Instruction Manual J-3732

Product Description

The 57C385 unit is a replacement battery that was designed to be used within AutoMax PLCs that were designed and produced by Reliance Electric. At AX Control, we make our best effort to stock these replacement batteries as often as possible. Call or email us to check on the availability of the 57C385 replacement battery and to place your order.

The 57C385 unit is rated as being a 3.6 Volt, 2400 mA battery. It is a AA cell lithium thionyl chloride battery with a button top connector type and a shelf life of 10 years.

Upon receiving the 57C385 replacement battery from us, be sure to store it in a proper storage and follow the correct procedures. The battery, when not in use, should be stored in a container, preferable the original one, where it is safely away from any flammable materials. Be sure to keep track of how long the battery is being stored, making sure that an unused battery is not stored for longer than 10 years and to ventilate the storage area in the case of a fire. Be sure that the 57C385 replacement battery is stored at room temperature at a relative humidity of less than 65%.

To remove an old battery and install a new 57C385 replacement battery, be sure to follow the proper procedures and safety precautions as outlined in the product’s manual. Be sure to turn off the power to the system and remove all power to the rack. Loosen the screws that hole the module in the rack and remove the module from its slot. Then, take the old battery out of the holder and dispose of it in accordance with proper guidelines. Place the new battery into the slot. After doing this, reinsert the module into the correct slot within the rack. You may then reapply power to the rack. If you have done this correctly, the PLC will automatically begin its power up diagnostic procedure, where the status indicator labeled “BAT OK” will illuminate.

The approximate weight of the 57C385 replacement battery is 0.10 lbs. or 0.045 kg.

Frequently Asked Questions about 57C385

What is 57C385 a replacement battery for?
57C385 is a replacement battery for either the AutoMax Processor Module or Common Memory Module.
What type of battery is 57C385?
57C385 is a 3.6 volt Lithium AA battery.
What is the retention span on 57C385?
57C385 holds up longer with some modules rather than others. When 57C385 is used with M/N 57C430A, 57C385 has a typical retention span of 333 days. When 57C385 is used with M/N 57C431, 57C385 usually holds up for 9.6 years.
