Universal Drive Controller Reliance Automax

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 57652 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 57652
  • SKU: 57652RE
  • Manufacturer: Reliance Electric
  • Series: AutoMax PLC

57652 Technical Specifications

Manufacturer Reliance Electric
Series AutoMax PLC
Part Number 57652
Product Type Universal Drive Controller
Instruction Manual S-3007

Product Description

The 57652 is a Drive Controller created by Reliance Electric. Depending on when it was mass-produced this controller may have also been listed under the Asea Brown Boveri or Baldor Reliance product lines. This controller is no longer being supported by those manufacturers. AX Control does try to keep this item in stock though. We typically have it as either a refurbished or new surplus stock item. Please refer to our website to see if this item is available.

The 57652 is an AutoMax Universal Drive Controller (UDC) module. The UDC’s main function is to control one or two AC and/or DC drives. Up to 10 different UDCs can be placed on the storage rack at one time, which allows the rack to control up to twenty AC or DC drives. It can be plugged into an AutoMax storage rack, attaching to the backplane. The UDC has the capability to talk to AutoMax processors that are also present on the storage rack.

The 57652 has a non-volatile flash memory installed onto it. This memory has the ability to keep the UDC tasks, the drive configuration information, and the operating systems for the UDC and the Power Module Interfaces. To be able to exchange data with the processors on the rack, the UDC has a dual-port memory. This memory allows it to act as a storage buffer.

The 57652 the main parts of this device are a printed circuit board and a housing enclosure. It also has a faceplate. This module has a bank of LED lights that are labeled DRV B FLT, COMM B OK, DRV A FLT, COMM A OK, OK OK, and CARD OK. On its faceplate, it has test switches, ports for Comm A and Comm B, and meter ports. It also has two mounting brackets; one on the top and one on the bottom. This allows for easy mounting to the storage rack.

Frequently Asked Questions about 57652

What kind of memory does 57652 have?
57652 has EM memory.
How many positions can the test switch on 57652 be in?
The test switch on 57652 can be in position 1, 2, or 3.
Where can I find the manual for 57652?
The manual for 57652 is Manual S-3007. The manual is a Reliance manual and the manual will give additional information on 57652. You can find the manual online or we can send you the manual to 57652.

Repair Services For 57652

Type Lead Time Price Action
Repair Service 1-2 weeks $333

Our highly skilled technicians can repair your 57652. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
