0-57414-1D Modbus Gateway Interface I/O Module B206750.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 57414 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

57414

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.83 (6)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.83 (6)
  • Click a star to rate this product
0-57414-1D Modbus Gateway Interface I/O Module B206750.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 57414 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

57414 Technical Specifications

Manufacturer Reliance Electric
Part Number 57414
Product Type Modbus Interface Module
Series AutoMax PLC

Product Description

Reliance Electric created the 57414 Modbus Interface Module. Baldor Electric and Asea Brown Boveri may have also sold the 57414 depending on when it was created. This module is not being supported by any of the manufacturers anymore. AX Control does try to keep it in stock though. Please see our website for the availability of the 57414. We typically sell it as a refurbished or new surplus stock product.

The 57414 is a Modbus Assembly Gateway Module created for the AutoMax control system. This module’s main purpose is to connect and encourage communication between AutoMax and Modbus-compatible devices. It does this using a specific subset of the Modbus message function set.  In order to create a single Modicon 584 type module, the 57414 can convert up to four AutoMax Processor Modules. This can then be viewed by the Modbus link. Both RTU and Modbus ASCII modes are supported by this module.

The 57414 has a set of LEDs. There is a 7-segment LED display that can tell you status and error codes. There is an LED labeled OK and it is there to let you know that the module is functioning within its parameters. There is a thumbwheel switch that allows you to select the drop or device number for the equipment. There is also an RS-232 gateway connection port that links the non-AutoMax equipment.

This module plugs into a typical AutoMax card assembly rack. It slides directly into a pair of card slots on the rack backplane. There are brackets on the rack and the faceplate of the module that can be used to further secure the 57414 into place.

Frequently Asked Questions about 57414

What does 57414 integrate with?
57414 integrates with Modicon 984 via RS-232 connection.
How many thumbwheel switches does 57414 have?
57414 has two thumbwheel switches on the 57414 faceplate for selecting the nodes, which are 01 to 99 on 57414.
Where can I get help with troubleshooting a Reliance 57414?
You shouldn't have many troubleshooting issues with 57414 because 57414 is an interface. Though if you do have troubleshooting questions about 57414, please call us at AX Control. Our experts will help you with any AutoMax/AutoMate troubleshooting needs.
