Reliance Resolver Input Module 57C411.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 57411 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

57411

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.67 (9)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.67 (9)
  • Click a star to rate this product
Reliance Resolver Input Module 57C411.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 57411 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

57411 Technical Specifications

Instruction Manual J-3640
Manufacturer Reliance Electric
Part Number 57411
Product Type Resolver Input Module
Series AutoMax PLC

Product Description

The 57411 is a Reliance Electric made Resolver Input Module. Baldor Reliance or Asea Brown Boveri may have also produced this module depending on when it was released. These manufacturers do not offer support for the 57411 anymore. AX Control does try to keep it in stock, however, as a reconditioned or new surplus stock item. Please check out our website for the availability status of the 57411.

The 57411 was created to be a part of the DCS 5000 system. Its main function is to tell the DCS 5000 the angular position of a resolver rotor. It has the ability to determine the position of the rotary shaft and the velocity of the device. This module can give a 12-bit resolution of one revolution and a 2-bit counter-revolution. This module can be used to interrupt the rotors on every sample.

The 57411 is a printed circuit board with a faceplate that is encased in a protective enclosure. It is typically plugged into the backplane of a DCS 5000 storage rack using the female card slots on the backplane. From there, you can secure the card into place by attaching the brackets on the rack, the brackets on the module, and two screws.  The brackets on the faceplate can also be used to help you easily remove the module from the rack. The input signals coming into the board are coming in using a multiconductor cable. One end of it attaches to a terminal board and the other attaches to the faceplate connectors.

Frequently Asked Questions about 57411

How many LED indicators are on 57411?
57411 has 5 LED indicators on the 57411 faceplate, including one LED that indicates when 57411 is on or off.
What kind of converter does 57411 have?
57411 has a tracking resolver-to-digital converter that produces a 12-bit digital number proportional to an electrical revolution of a resolver.
How many electrical revolutions can the 2-bit electronic counter on 57411 count?
The 2-bit electronic counter on 57411 can count 4 electrical resolver revolutions.
Where can I find the manual for 57411?
We have the manual for 57411 available for you. The manual is the Resolver Input Module Manual, Manual J-3640, so it is the manual specifically made for 57411. Please ask us for a link to the 57411 manual or find the manual on our site.
  • 57411-1
  • 57411-1A
  • 57411-2
  • 57411-2A
  • 57411-2B
  • 57411-2C
  • 57411-2D
  • 57411-2E
  • 57411-2F
  • 57411-2G
  • 57411-2H
  • 57411-2I
  • 57411-2J
  • 57411-2K
  • 57411-2L
  • 57411-A
  • 57411-B
  • 57411-C

Repair Services For 57411

Type Lead Time Price Action
Repair Service 1-2 weeks $253

Our highly skilled technicians can repair your 57411. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

57411 Manuals, White Papers, Data Sheets, and Troubleshooting
