Reliance Electric AutoMax 57408 Interface Power Module 57 408

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 57408 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

57408

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (5)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (5)
  • Click a star to rate this product
Reliance Electric AutoMax 57408 Interface Power Module 57 408

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 57408 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

57408 Technical Specifications

Instruction Manual D-2717
Manufacturer Reliance Electric
Part Number 57408
Product Type Interface Power Module
Series AutoMax PLC

Product Description

The 57408 is a Power Module Interface for an AutoMax controller system that was made by Reliance Electric. There is a strong possibility that this interface was also produced by Baldor Reliance and Asea Brown Boveri depending on what years it was actually in production.

The 57408 is comprised of a printed circuit board and faceplate that are almost completely encased in a protective chassis. The back of the board is exposed. This unit plugs directly into an AutoMax Storage Rack Assembly. You can slide this card into two card slots on the backplane of the rack and then completely secure the module into place using two sets of brackets on the rack and on the faceplate. The brackets on the faceplate can also be used to easily slide the module out of the rack assembly.

On the faceplate of the 57408, there are three sets of RS-232 female connectors. They are clearly labeled TO POWER MODULE, TO ANALOG I/O, and TO DRIVE CONTROLLER. There is a set of four terminals that can have wires connected to it. These terminals are labeled as CURRENT CALIBRATION.  There is a small white label on the left side of the module that will give you specific product specifications.

The 57408 is no longer being maintained by any of the previous manufacturing companies. However, AX Control does try to keep it in stock. We will typically offer this item as a reconditioned or new surplus item. Please check our website for its availability and shipping options.

Frequently Asked Questions about 57408

What are the connections on 57408 to?
57408 has connections P3, P4, and P5. P3 on 57408 is the connection to the power module. P4 on 57408 is the analog I/O connection. P5 on 57408 is the drive controller connection.
What manual goes with 57408?
The manual that goes with 57408 is Manual D-2717. The manual is a Reliance manual for 57408 and we're happy to send you the link to the manual.
What type of calibration does 57408 have?
57408 has current calibration with 57408 having four calibration knobs.
  • 57408-1
  • 57408-1A
  • 57408-1B
  • 57408-1C
  • 57408-A
  • 57408-B
  • 57408-C
  • 57408-D

Repair Services For 57408

Type Lead Time Price Action
Repair Service 1-2 weeks $215

Our highly skilled technicians can repair your 57408. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
