Network Communications Module Circuit Rev.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 57404 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 57404
  • SKU: 57404RE
  • Manufacturer: Reliance Electric
  • Series: AutoMax PLC

57404 Technical Specifications

Manufacturer Reliance Electric
Series AutoMax PLC
Part Number 57404
Product Type Network Communications Module
Instruction Manual J2-3001

Product Description

The 57404 unit was designed and manufactured to be a Network Communications module by Reliance Electric. This particular module was designed to be used along with the AutoMax DCS-NET network. The 57404 network communications module is no longer in production, but AX Control continues to supply it and may have it in stock currently. The availability of this product is listed on this page, but you can always contact us if you have any further questions about its availability or the method in which we ship our orders.

In general, the 57404 network communications module consists of three main components: the faceplate, the printed circuit board, and the enclosure.

The faceplate has many different components placed on it. There are ejector tabs that are located on the top or bottom. These ejector tabs were implemented so that the operator can easily remove the module from the rack in which it has been inserted. There is also a 25-pin D-shell connector placed on the faceplate that has the label “MONITOR” next to it. This D-shell connector is meant to be used for the RS-232 compatible asynchronous link. There is also a 9-pin D-shell connector labeled as the “NETWORK” connector, two thumbwheel switches, indicator lights, and a seven segment LED display for error codes.

The internal printed circuit board controls the 57404 network communications module’s processes. This includes a watchdog timer, an on board CPU, the status indicator lights, and the LED display. The 57404 network communications module’s circuit board will enable the module to run numerous diagnostics.

The protective enclosure contains the contents of the 57404 network communications module and protects it from any hazardous conditions.

Frequently Asked Questions about 57404

Where do I find the manual for 57404?
We're happy to provide you with the 57404 manual. The manual is the Network Communications Module Manual, Manual J2-3001, and the manual guides you through descriptions and troubleshooting a 57404.
How many LED's are on 57404?
57404 has a seven-segment LED on the faceplate of 57404. The LED's on 57404 display fault codes or error codes. You can identify the fault codes in Appendix D of the Network Communications Module Manual.
What do the thumbwheel switches do on 57404?
The thumbwheel switches on 57404 are used to set the network drop number.
