Reliance Electric Automax Processor Module.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 45C409 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 45C409
  • SKU: 45C409RE
  • Manufacturer: Reliance Electric
  • Series: AutoMax PLC

45C409 Technical Specifications

Manufacturer Reliance Electric
Series AutoMate PLC
Part Number 45C409
Product Type Control Processor

Product Description

The 45C409 is a control processor module that Reliance Electric created to be used with AutoMate programmable logic controllers. This module is no longer being produced by the original manufacturer, but AX Control usually has this product in stock. Contact us to check on this device’s availability in our stock.

The 45C409 control processor module, along with the 45C400 logic processor module, is a component that comes with the AutoMate 40X controller module. The AutoMate 40X controller module is used for smaller applications. By using the 45C409 control processor module and the 45C400 logic processor module, the AutoMate 40X controller module will address up to 1024 digital I/O. Every single processor set will be expanded to up to 104K x 16 non-volatile application memory by adding up to two memory expansion cards. All of the processor sets have 8K x 16 non-volatile application memory to be used. All of the AutoMate 40 processors have identical software programming features, ensuring that installation is streamlined, especially for those familiar with the system. The software includes all of the features of the Enhanced AutoMate 30 controllers plus additional instruction blocks to introduce improved communications.

The 45C409 control processor module possesses a Motorola 68000 microprocessor to perform advanced software functions. These advanced software functions such as data conversion, mathematics, ASCII communications, program flow control, and many more functions. In addition to that, the 45C409 control processor module has its own LED status indicator lights and an RS-232 communication port.

The 45C409 control processor module has a total weight of about 2.00 lbs. or 0.91 kg. Be aware that this total does not include any of the shipping materials we use to furnish our packages.

Frequently Asked Questions about 45C409

What functions does 45C409 perform?
45C409 performs advanced function softwares. 45C409 performs mathematics. 45C409 performs data conversion. 45C409 performs program flow control. 45C409 performs ASCII communications. And 45C409 does much more.
What microprocessor does 45C409 use?
45C409 uses a Motorola 68000 microprocessor.
  • 45C409A
  • 45C409B
  • 45C409C
  • 45C409D

Repair Services For 45C409

Type Lead Time Price Action
Repair Service 1-2 weeks $323

Our highly skilled technicians can repair your 45C409. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
