Reliance Electric AutoMax 45C400 Module, Logic Processor 45 C 400

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 45C400 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 45C400
  • SKU: 45C400RE
  • Manufacturer: Reliance Electric
  • Series: AutoMax PLC

45C400 Technical Specifications

Manufacturer Reliance Electric
Series AutoMate PLC
Part Number 45C400
Product Type Logic Processor

About the 45C400

The 45C400 model is a logic processor module that was designed and manufactured by Reliance Electric, although this device’s production has since been stopped by them. If you are in need of the 45C400 logic processor module for your facility, then AX Control may have it. You can look on our website or contact us to verify this product’s availability within our stock.

The 45C400 logic processor module’s faceplate only has a few components on it. At the top of the faceplate, there are four status indicator lights. Each of these lights are labeled from top to bottom as follows: “RUN,” “FORCING,” “READY,” and “RAIL FAULT.” At the bottom of the 45C400 logic processor module, there are four I/O ports. These ports are labeled using the numbers 0 through 3.

The 45C400 logic processor module is a standard component in the AutoMate 40 controller package along with the 45C10 control processor module. The logic processor module uses its own dedicated logic so that it can solve ladder functions at very high speeds. This device has a total of four I/O ports that it uses to communicate with four rails for a maximum of 64 digital or 16 analog I/O, four local heads for up to 256 digital or 64 analog I/O, or any mix of local heads and I/O rails. The 45C400 logic processor module’s communications are designed to take place at 250K baud. Its data integrity is insured by use of parity.

The 45C400 logic processor module has an approximate weight of 1.85 lbs. or 0.84 kg.

Frequently Asked Questions about 45C400

What does 45C400 do?
45C400 uses dedicated logic to solve ladder functions at extremely high speed.
How many I/O ports does 45C400 have?
45C400 has four I/O ports to communicate directly to four rails for up to 64 digital or 16 analog I/O.
How fast are communications on a Reliance 45C400?
On 45C400, communications take place at 250K baud.
  • 45C400A
  • 45C400B
  • 45C400C
  • 45C400D

Repair Services For 45C400

Type Lead Time Price Action
Repair Service 1-2 weeks $279

Our highly skilled technicians can repair your 45C400. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
