45C40

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.36 (11)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.36 (11)
  • Click a star to rate this product
Rockwell Automate DCS 5000 115V I/O Input Module .

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 45C40 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 45C40
  • SKU: 45C40RE
  • Manufacturer: Reliance Electric
  • Series: AutoMax PLC

45C40 Technical Specifications

Manufacturer Reliance Electric
Series AutoMax PLC
Part Number 45C40
Product Type Dual A-C/D-C Input Module
Instruction Manual J-3012

About the 45C40

The 45C40 unit is a dual AC/DC input module that was made by Reliance Electric to be included as part of the AutoMax series. The 45C40 dual input module is no longer in production, but AX Control possibly still has this product in stock. Be sure to reach out to use either via phone or email to verify the availability of this product and place your order today.

The 45C40 dual input module has a total of 2 channels, which each have a response time of 9.5 ms at 60 Hz. The turn on time is 2.0 ms after the threshold is exceeded and the turn off time is 19.0 ms after the threshold is removed.

The 45C40 dual input module has many different voltage ratings based on the current type and whether or not the device is turned on or off. The nominal AC/DC voltage is 115 Volts, with an impedance at the nominal voltage being 18.1 kiloOhms. For the AC voltage, the ON threshold is 80 Volts and the OFF threshold is 60 Volts. For the DC voltage, the ON threshold is 108 Volts and the OFF threshold is 83 Volts. All of that being said, the 45C40 dual input module’s maximum input voltage is 130 Volts.

The 45C40 dual input module has a total weight of approximately 0.31 lbs. or 0.14 kg., not including packaging materials. The 45C40 dual input module’s dimensions are 2.1 centimeters (height) x 7.6 centimeters (width) x 15.5 centimeters (depth).

Frequently Asked Questions about 45C40

Is 45C40 the only dual A-C/D-C input module?
No. 45C40 is one of three A-C/D-C input modules.
How much power does 45C40 have?
45C40 has 120 VAC/DC power.
How do I know that the right amount of current is being drawn through on a 45C40?
There is a minimum-current resistory at each of 45C40's inputs to make sure sufficient current is drawn through the 45C40 to inhibit contact-film buildup.
What manual do I use with 45C40?
Manual J-3012, the AutoMate DCS 5000/AutoMax Digital I/O Rails and Modules Manual, is the manual specific to 45C40. You can find the manual via AX Control.
  • 45C40A
  • 45C40B
  • 45C40C
  • 45C40D

Repair Services For 45C40

Type Lead Time Price Action
Repair Service 1-2 weeks $392

Our highly skilled technicians can repair your 45C40. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
