Reliance Electric AutoMax 45C203 Serial Communications Processor 45 C 203

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 45C203 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 45C203
  • SKU: 45C203RE
  • Manufacturer: Reliance Electric
  • Series: AutoMax PLC

45C203 Technical Specifications

Manufacturer Reliance Electric
Series AutoMate PLC
Part Number 45C203
Product Type Serial Communication Processor

About the 45C203

The 45C203 is a Reliance Electric produced Serial Communication Processor. This processor may have been also created by Asea Brown Boveri and Reliance Electric depending on what year it was in production. This processor has been discontinued by the manufacturers and is no longer available for purchase directly for them. AX Control does attempt to have this part in stock when possible. Please contact us directly to see if it is available and what condition it is in.

The 45C203 was created to go along with an AutoMate 30/40 series controller. This is considered to be in the Microprocessor-based I/O card family. This card is designed to control issues that crop up independently of the AutoMate processor. By allowing the 45C203 to function this way, the AutoMate is then free to perform its own functions and reducing system scan times.  It allows for communication between typical RS-232 or 20mA devices, printers, and host computers. There are two types of functions this device can perform. It can be in a host computer mode, which allows it to talk to a terminal device and alter I/O points, controller status, and registers. The second mode it can be in is program control mode. This mode allows the processor to be controlled by the user’s application program and to send and receive messages.

The 45C203 has basic features include DB25 connectors, an on-board power supply, and 3 serial communication channels. It also maintains software-selectable communication parameters, baud rate, and parity. It has electrical isolation and RS-232 or 20mA Signals.

Frequently Asked Questions about 45C203

What does 45C203 allow AutoMate controllers to connect to?
Because of 45C203, AutoMate 30/40 controllers can connect to different peripheral devices. 45C203 allows controllers to interface with CRTs, printers, host computers, and other devices.
What modes can 45C203 operate under?
45C203 can operate under two modes. 45C203 can operate in computer mode or 45C203 can operate in program control mode.
How many communication channels does 45C203 have?
45C203 has 3 serial communication channels.
  • 45C203A
  • 45C203B
  • 45C203C
  • 45C203D

Repair Services For 45C203

Type Lead Time Price Action
Repair Service 1-2 weeks $310

Our highly skilled technicians can repair your 45C203. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
