0-57554- Technical Specifications

Instruction Manual J-3606
Manufacturer Reliance Electric
Part Number 0-57554-
Product Type Shark Interface Module
Series AutoMax PLC

Product Description

The 0-57554- is a Remote I/O Interface Module. Depending on what year it was in production, it may have also been a part of the Baldor Reliance or the Asea Brown Boveri product lines. This module may also be found under the part number ABB 57C554. This module has been discontinued by the manufacturers and is no longer available to be purchased directly from them. AX Control does try to keep the 0-57554- in stock though. Product availability is listed on our website.

The 0-57554- is also known as a PLC PC Board or a Shark Interface Module. It was created as part of the Reliance Electric AutoMax Remote I/O Interface systems. This module interfaces to the Shark’s backplane using a microprocessor. It does this by using timing and buffer circuitry. This module uses a +5 VDC power supply to power its logic circuitry. There is a separate power supply that is mounted onto the rack that supplies power to the module’s I/O network. It is rated at a+24 VDC and regulated at +12 VDC.

The 0-57554- has two LED indicator lights that are labeled CPU OK and COM OK. It has a Drop Number dial and a male RJ snub connector labeled NETWORK.

For more information about the installation of the 0-57554- please consult Instruction Manual J-3606. Only a proficient specialist should attempt to connect the 0-57554- to prevent damage to the 0-57554- and personal injury.

Frequently Asked Questions about 0-57554-

Where can I find a diagram of the Reliance 0-57554-?
Figure 2.2 in the AutoMax I/O Remote Communications Manual displays a diagram of the 0-57554- faceplate. We are happy to send you a link to that manual.
Are there status indicators on a Reliance 0-57554-?
Yes, 0-57554- has status indicators. 0-57554- has two status LEDs. 0-57554- has a CPU OK LED and a COM OK LED status indicator.
What is the rotary switch used for on 0-57554-?
The rotary switch on 0-57554- is 16-position and on 0-57554-, it is used to select the Shark rack's Remote I/O drop number. The switch on 0-57554- is only read on power-up.
  • 0-57554-1
  • 0-57554-B

Repair Services For 0-57554-

Type Lead Time Price Action
Repair Service 1-2 weeks $304

Our highly skilled technicians can repair your 0-57554-. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
