ST402-AG41-24V Model by Digital Electronics Corporation of Japan Proface Resolution 320 x 240 3.8-in touch panel HMI with an Amber backlit LCD screen

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a ST402-AG41-24V to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

ST402-AG41-24V

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
ST402-AG41-24V Model by Digital Electronics Corporation of Japan Proface Resolution 320 x 240 3.8-in touch panel HMI with an Amber backlit LCD screen

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a ST402-AG41-24V to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

ST402-AG41-24V Technical Specifications

Manual ST Series User Manual
Manufacturer Pro-face
Model Name ST402
Model Type ST402-AG41-24V
Resolution 320 x 240 pixels
Series ST400
Type Monochrome LCD

Product Description

The ST402-AG41-24V is an HMI operator interface controller from Pro-face. This small unit offers multiple features, including:

  • Recipe and batch monitoring
  • The ability to script custom applications
  • Data logging
  • Real-time monitoring of process automation and discrete automation information
  • Management of both active and historical alarms

The ST402-AG41-24V has a 3.8 amber graphic touch screen. Internally it offers a 100 Mhz RISC processor. The unit also has six function buttons (configurable) per screen and offers barcode support to allow for parts tracking and inventory control. The ST402-AG41-24V can connect to various Siemens interfaces using its limited RS-422 serial port or Siemens MPI RS-485 COM port. This also supports serial devices like a barcode reader. The unit is powered by GP-Pro/PB III C software. This is password protected and allows for graphics editing for drawing objects or for animations.

The ST402-AG41-24V screen has eight adjustment levels available for contrast and two brightness control levels. Display resolution is 320 x 240 pixels. This is an amber monochrome LCD display offering up to eight gray levels. Application memory is 640KB via a Flash Eprom with 96KB SRAM data backup. The unit requires 24 VDC input voltage. For additional information about this product, please review the original documentation from ProFace Xycom. Manuals, datasheets, and user guides should be reviewed before any maintenance is started. This information is vital to user safety.

AX Control ships globally. We can typically ship your in-stock product within hours of order placement. Please order by 3 pm to give us time to pull products before our last shipment of the day.

Reviews For ST402-AG41-24V
Internal Review

This small amber LCD graphic touch panel offers a wide variety of standard features including data logging, recipe and batch monitoring, and active and historical alarm management. If you need a small LCD HMI that can support a barcode reader or other serial devices, this is a good option. --AX Control Tech Team.

Repair Services For ST402-AG41-24V

Type Lead Time Price Action
Repair Service 1-2 weeks $504

Our highly skilled technicians can repair your ST402-AG41-24V. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

ST402-AG41-24V Manuals, White Papers, Data Sheets, and Troubleshooting
