PFXSP5690WAD

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
Pro-Face Unit PFXSP5690WAD 12.1-inch Widescreen for Series SP5000X. Alternate Model Number SP-5690WA / PFXSP5690WADF0H. Resolution 1,280 x 800 pixels (WXGA).

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a PFXSP5690WAD to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: PFXSP5690WAD
  • SKU: PFXSP5690WADPX
  • Manufacturer: Pro-face Xycom
  • Series: SP5000X Series

Image Coming Soon

3 year warranty

PFXSP5690WAD

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
Pro-Face Unit PFXSP5690WAD 12.1-inch Widescreen for Series SP5000X. Alternate Model Number SP-5690WA / PFXSP5690WADF0H. Resolution 1,280 x 800 pixels (WXGA).

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a PFXSP5690WAD to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: PFXSP5690WAD
  • SKU: PFXSP5690WADPX
  • Manufacturer: Pro-face Xycom
  • Series: SP5000X Series

PFXSP5690WAD Technical Specifications

Display Colors 262,144 colors
Effective Display Area 261.1 x 163.2 mm (10.28 x 6.43 in)
Environment Rating IP66F, IP67F, Type 4X (indoor and outdoor use)
External Dimensions 308 x 230.5 x 68 mm (12.15 x 9.07 x 2.68 in)
Resolution 1,280 x 800 pixels (WXGA)
Weight 3.2 kg (7.1 lb) or less

Product Description

A 12-inch wide display monitor from Pro-face is product PFXSP5690WAD. It is in the HMI family, and part of the SP5000X Series. It comes with more than 260,000 display colors and uses a white LED backlight with 50,000 hours or more of service life. There are also 100 levels of brightness control. Model PFXSP5690WAD should be used and stored in temperatures between -22 and 158 degrees Fahrenheit. However, it should be installed in temperatures between 23 and 158 degrees. This monitor can withstand altitudes of up to 6,561 feet, and air pressure from 800 to 1,114 hPa. Product PFXSP5690WAD weighs just over seven pounds.

Make sure to always cool off this monitor through natural air circulation. The product consumes a maximum of 37 watts of power and a minimum of 12.5 watts or less. It has input voltage limits ranging from 10.8 to 28.8 Vdc. The allowable voltage drop is between 1.25 ms. And 5 ms. It uses a noise voltage of 1,000 Vp-p and has an insulation resistance of 500 Vdc. Model PFXSP5690WAD has been discontinued by Pro-face, but can be found through other suppliers, such as AX Control. Alternate part numbers are SP-5690WA and PFXSP5690WADF0H

Reviews For PFXSP5690WAD
Internal Review

The LCD screen may show unevenness in the brightness of certain images or may appear different when seen from outside the specified viewing angle. Extended shadows or crosstalk may also appear on the sides of screen images. - AX Control Inc.

Repair Services For PFXSP5690WAD

Type Lead Time Price Action
Repair Service 1-2 weeks $1712

Our highly skilled technicians can repair your PFXSP5690WAD. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
