The Proface by Scheider Electric unit PFXSP5490WA (SP-5490WA) is a Modular 7-inch Wide TFT LCD with a resolution of 800 x 480 pixels (WVGA).

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a PFXSP5490WA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: PFXSP5490WA
  • SKU: PFXSP5490WAPX
  • Manufacturer: Pro-face Xycom
  • Series: SP5000X Series

PFXSP5490WA

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
The Proface by Scheider Electric unit PFXSP5490WA (SP-5490WA) is a Modular 7-inch Wide TFT LCD with a resolution of 800 x 480 pixels (WVGA).

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a PFXSP5490WA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: PFXSP5490WA
  • SKU: PFXSP5490WAPX
  • Manufacturer: Pro-face Xycom
  • Series: SP5000X Series

PFXSP5490WA Technical Specifications

Dimensions 203.6 x 148.6 x 37 mm (8.02 x 5.85 x 1.45 in)
Display Color 262,144 colors
Display Type TFT Color LCD (High brightness)
Enclosure Type IP66F, IP67F, Type 4X (indoor and outdoor use), Type 12, Type13
Features White LED (Not user replaceable)
Input Voltage 12...24 Vdc
Manufacturer Pro-Face by Schneider Electric
Model SP-5490WA
Power Consumption Max. 29 W
Resolution 800 x 480 pixels (WVGA)
Screen Size 7” wide

Product Description

Product PFXSP5490WA SP-5490WA PFXSP5490WAF0H is part of the SP5000 series from Pro-face. This display monitor also has model number SP-5490WA. The monitor has 262,144 colors, and a graphics resolution of 800 x 480 pixels. The backlight is a nonreplaceable white LED, which has a service life of 50,000 hours or more. The display area is 6 x 3.6 inches, and a resistive analog touch panel offers brightness control ranging from 0 to 100. The touch panel has a resolution of 1,024 x 1,024.

Model SP-5490WA has a rated input voltage of 12 to 24 Vdc, and an inrush current of 30 A or less. Storage temperature for this product can range from -22 to 158 degrees Fahrenheit. Storage humidity should be kept between 10% and 90% RH. The product weighs 2.9 pounds or less, and should always be cooled through natural air circulation. It consumes 29 watts or less of power and has input voltage limits of 10.8 to 28.8 Vdc. When the screen backlight is at 20%, the display monitor consumes 15 watts or less of power.

We also offer the alternate Model Number PFXSP5490WAF0H (under the Revisions tab) if a conformal coated model is required. AX Control Inc. can also buy, sell, or repair these monitors.

  • SP-5490WA
  • PFXSP5490WAF0H
Reviews For PFXSP5490WA
Internal Review

The color TFT LCD panel offers a wider viewing angle than many older STN or Monochrome Pro-Face display panels and will enhance clarity when the user is standing to the side of the unit rather than directly in front of it. - AX Control Tech

Repair Services For PFXSP5490WA

Type Lead Time Price Action
Repair Service 1-2 weeks $1063

Our highly skilled technicians can repair your PFXSP5490WA. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
